Help CenterHDPE Geomembrane for Landfill Projects
Related Products
-
Geomembrane for LandfillUS$ 0.5 - 3MOQ: 2000 Square Meters -
HDPE Geomembrane 0.5mm-3.0mm/Black Sheeting/ASTM StandardUS$ 0.5 - 3MOQ: 2000 Square Meters
-
HDPE Geomembrane for Landfill(0.2-3.0mm)US$ 0.5 - 3MOQ: 2000 Square Meters
-
Pond Liners(HDPE Geomembrane)US$ 0.96 - 6.98MOQ: 5000 Square Meters
-
GeomembranesUS$ 0.3 - 8MOQ: 1 Square Meter
HDPE geomembrane,a waterproof material,compound with geotechnological fabric and geomembrane , it is used for draining off water and adding the muscle mainly. It divides into one cloth one membrane and two cloth first membrane,width 4-6m,weight range is 200-1500g/m2.
The hdpe geomembrane is against drawing, tearing resistance,and high CBR plunger strength, can meet the need of civil engineering such as water conservancy , municipal administration,building,traffic,subway,tunnel etc.Because of selecting high polymer materials for use and adding the aging-resistant materials in the production technology, it can use in the unconventional temperature environment.
Technical Data
Item and Art No. |
PLD0601 |
PLD0602 |
PLD0603 |
PLD0604 |
PLD0605 |
PLD0606 |
PLD0607 |
Unit weight, g/m2 |
400 |
500 |
600 |
700 |
800 |
900 |
1000 |
|
Break strength, kN/m |
5 |
7.5 |
10.0 |
12.0 |
14.0 |
16.0 |
18.0 |
MD/CD CBR Plunger Strength,kN |
1.1 |
1.5 |
1.9 |
2.2 |
2.5 |
2.8 |
3.0 |
Tear strength, kN |
0.15 |
0.25 |
0.32 |
0.40 |
0.48 |
0.56 |
0.62 |
Film thickness,mm |
0.25-0.35 |
0.3-0.5 |
|||||
HDPE Geomembrane
Features:
1.All physical factors such as anti-draw, anti-tear, and anti-stab meet the requirement of water works, chemicals, tunnels, and transportation project in most conditions.
2.Good aging, durable performance, and wide temperature arrange, it can be useful over thirty years on the condition of -60æ«60æ.
3.Anti-stab and fine friction factors.
4.Canker proof, acid and alkali proof, untoxic.
5.Lower cost per unit area, cost is 1/3«1/2 lower than that of PVC film, glass and cloth.
6.Convevient to install and dependable effect.
Specification:
Breadth:4-14m Thickness:0.18-1.5mm
Technical Data
Ordinary High Density Polyethylene Geomembrane (GH-1 Type)
Item |
Index |
||||||||
Thickness, mm |
0.30 |
0.50 |
0.75 |
1.00 |
1.25 |
1.50 |
2.00 |
2.50 |
3.00 |
Density, g/cm3 |
0.940 |
||||||||
Yield strength (MD/CD), ≥N/mm |
3 |
5 |
8 |
11 |
13 |
16 |
22 |
26 |
33 |
|
Break strength (MD/CD), ≥N/mm |
5 |
8 |
12 |
17 |
20 |
24 |
34 |
40 |
51 |
|
Yield elongation (MD/CD), ≥% |
/ |
/ |
/ |
11 |
|||||
|
Break elongation (MD/CD), ≥% |
450 |
||||||||
Right angle tear strength (MD/CD), ≥N |
24 |
40 |
60 |
80 |
100 |
120 |
160 |
200 |
240 |
Puncture-resistant strength, ≥N |
51 |
85 |
125 |
170 |
200 |
250 |
340 |
400 |
500 |
Carbon black content, % |
2.0-3.0 |
||||||||
Environmental Smooth High Density Polyethylene Geomembrane (GH-2S Type)
Item |
Index |
||||||
Thickness, mm |
0.75 |
1.00 |
1.25 |
1.50 |
2.00 |
2.50 |
3.00 |
Density, g/cm3 |
0.940 |
||||||
Yield strength (MD/CD), ≥N/mm |
11 |
15 |
18 |
22 |
29 |
37 |
44 |
Break strength (MD/CD), ≥N/mm |
20 |
27 |
33 |
40 |
53 |
67 |
80 |
Yield elongation (MD/CD), ≥% |
12 |
||||||
Break elongation (MD/CD), ≥% |
700 |
||||||
Right angle tear strength (MD/CD), ≥N |
93 |
125 |
160 |
190 |
250 |
315 |
375 |
Puncture-resistant strength, ≥N |
240 |
320 |
400 |
480 |
640 |
800 |
960 |
|
Environmental stress cracking time (single point of incision constant load stretching), ≥h |
/ |
300 |
|||||
Carbon black content, % |
2.0-3.0 |
||||||
Oxidation induction time (OIT), min |
Standard OIT≥100 High pressure OIT≥400 |
||||||
|
Oven aging at 85℃ Standard OIT retained after 90 days, ≥% |
55 |
||||||
|
UV resistance OIT retained after 1600hrs, ≥% |
50 |
||||||
