1.Inspection of BGA welding (bridge welding, open circuit, cold welding, void and so on) 2.Welding inspection of such super-fine parts as system LSI(broken circuit or continuous welding) 3.Inspection of packaged ICs, rectifiers, resistors, capacitors, connectors and other semiconductors 4.Inspection of PCBA welding 5.X-Ray examination of metal parts, heating elements, pearls, sinks, and lithium cells’ internal structures
Features:
1.Equipped with sealed-pipe-type maintenance-free micro-focus X-Ray tubes. 2.Equipped with stepless speed changing lever for convenient control of speed, angle and range. 3.All moving parts are equipped with ball screws and driven by steppers, so motions are smoother with high precision and lower noise. 4.High-voltage power source and X-Ray tubes are connected in a split way. If there is anything wrong with the power source, you do not have to replace the whole X-Ray system and it is also very convenient to maintain the power source. 5.Equipped with software to calculate the BGA void ratio automatically. 6.Automatic X-ray tube protection: if no operation happens on the system for 20 minutes, the system will turn off automatically and come into protection mode.
7.Automatic machine protection: if any door is opened,the unit will turn off immediately and come into protection mode and the X-ray emission stops immediately. 8.Calculates the cumulative operation time of the x-ray tube automatically. Inclination of the angle and automatic navigation function are optional.
[Measurement] 1.To measure the distance between two points, the angle between two lines, and the arc. 2.To measure the area of a rectangle and an ellipse. 3.To measure the length of the longest and the shortest axis. 4.To measure the bubble area ratio of irregular products. 5.To measure the curvature of a line.
[Measurement of BGA Void Percentage] 1.Single or multiple areas may be selected to calculate the BGA bubble ratio of the selected area automatically. 2.Limiting values may be set to judge void ratio, maximum void, or advantages and disadvantages automatically.
Packageing Details : wooden case or customised package
Delivery Details: 20 workingdays
1. The machine can be delivered by DHL, FedEx, TNT, EMS, UPS.
2. By sea or by air. Please provide us your nearest port.
3. The delivery date is within10 working days after the receipt of payment. If you are in urgent need of it,please kindly tell us.
1.Pre-consultation: provides professional SMT solutions for the full line.
2.Factory Warranty: One-year warranty factory service.
3.Installation: On-site installation and commissioning, to ensure smooth production.
4. Technical Training: provides professional training from Level 1 to Level 3.
5.Technical support:provides 7 * 24 technical support.
6.Software Upgrade: offers lifetime free software upgrades for all products.
ETA is the leading SMT factory solution provider in China,offering professional SMT factory building advice and service.We have 20 year experience about SMT factories,offering full solutions for global clients with our great advantaged sources.Our core technology team members are well experienced in SMT filed, learning experience from top international chip mounters meanwhile increasing independent research and development. Currently ETA SMT equipment is representative of high quality , has maintained absolute leading technology in the industry.
Over the years the company has been committed to improving technology, quality and perfect service. ETA makes a positive contribution to international standard,the annual total capacity of 1200 sets, passed the ISO9001: 2000, ISO14000, CE, UL, RoHS and other certifications. Full implementation of the IPD process, reliable design and testing throughout the entire product life cycle.ETA’s continued investment in research and development and great contribution has been unanimously recognized in the field. By the end of 2012, ETA has declared more than 30 patents and software copyrights (including four invention patents), and actively involved in a number of national and industry standards. ETA provides more advanced products and fast technical support for global customers, at home and abroad.
1. Quick response within 24 hours.
2. On time delivery.
3. Techinical support before and after sales.
Thanks for choosing ETA.
ETA looks forward to win-win cooperation.
