XT4502 gift wrapping machine

Specifications

1. Suit for wrapping big objects on pallet
2. Low consumption and high efficency
3. Easy operation

 Description:

Adopting programmable control(frequencu converter), reliable in performance, convenient in operation; The lapping type and time can be designed on custommer's requirements.

Equipped with a photoelectric detector, automatically testing the goods height and controlling the traval limit.

Rotary table can reset automatically, thus ensuring correctin-and out position of the tray.

Convenient in film roll replacement, LLDPE film with outside diameter≤ 280mm, width≤ 500mm and paper core 76mm can be used.

Custom-made specification is available and also providing a complete set of packing system of conveying line.

Percent of pre-stretch: 250%

It can protect the package against dust and damp, and make the package clean. It can decrease the scratch of the package, improve the surface quality, and make the package more secure.

turntable motor:	750 w
film-rack lift motor:	180 w
power supply:	220V/380V  50HZ
dimension:	1510*2500*2600 mm
max. packing height:	2100 mm
max. packing weight:	2000 kg
diameter of turntable:	1500 mm
net weight:	530 kg
