ETA SMT Lead-Free Reflow Oven
US$ 5,000 - 60,000
/ Case
1 Case(Min. Order)
- HONGKONG
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | ETA | |
| Model Number | REFLOW OVEN | Usage | SMT | |
| Voltage | 380/220v | Weight | 1500 | |
| Dimensions | 5000*1250*1500mm | Rated Duty Cycle | 5 | |
| Rated Capacity | 35KW | Current | 60A | |
| Certification | ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
ETA SMT Lead-Free Reflow Oven
(Nitrogen Lead Free Reflow Oven E10-N is available also.)
Model: E10 Lead-free Reflow Oven(10-zone)
Brief: smt lead-free reflow oven
Model: E10 Lead-free Reflow Oven(10-zone)
Brief: smt lead-free reflow oven
Heating System
> Eight groups of top and bottom forced hot air convection heating zones.
> Patented heating plates in each zone uniformly transfer heat to the PCBs using forced hot air convection.
> Independent temperature control in each zone to ensure temperature uniformity within the process tunnel.
> Audible and light tower alarm for temperature limits, PCB drop, PCB jam and blower malfunction.
> Fast start-up (within 20 minutes) from room temperature to work temperature due to the high efficiency of the motorized heating plates.
Cooling System
> Two (2) groups of forced air convection cooling zones.
Distortion-free Conveyor System with Automated Chain Lubrication
> Closed-loop computer control of the conveyor provides a precise and repeatable reflow process.
> Automated chain lubrication system with a computer controlled central reservoir. Lubricant is added directly to the conveyor brush eliminating operator interface for this maintenance.
Fresh Air Recharge System
> Fresh air is supplied to each zone uniformly to provide a rapid process transfer.
Flux Management System
> Air amplifier forces supercharged flux collection and recirculation.
> Flux exhaust chimney with drawer shaped filter net is easy to access for maintenance.
Additional Features
> Integrated UPS will be automatically activated in case of main power failure and will keep control PC and conveyor running for minimum 8 minutes to send out PCBs inside the oven tunnel.
> Motorized hood lift allows easy access to the inside of the oven for service and maintenance.
> Five (5) profiling ports and integrated profiling software are designed for convenient temperature profiling.
> Swing arm control PC station
> Four (4) emergency stop switches
> Two (2) exhaust ports
> SMEMA interface
> System documentation
