MPM SMT PRINTER, MPM SMT stencil PRINTER CHINA AGENT
PCBA Printer,SOLDER PASTE PRINTER
- 1. Product Features:
a) Wide compatibility for PCB dimensions from 50mm x 70mm to 700mm x 500mm and PCB thickness from 0.8mm to 6mm
b) High printing resolution
- 1. High positional accuracy, repeated positioning accuracy ±0.01mm; printing accuracy 0.025mm.
- 2. Support glue printing
c) Automatic control improves production efficiency, quality control and saves production cost:
- 1. Automatic steel mesh positioning;
- 2. Automatic PCB alignment;
- 3. Automatic adjustment of squeegee pressure;
- 4. Automatic printing;
- 5. Automatic stencil cleaning (dry-type, wet-type and vacuum-type);
- 6. Adopt company independently developed suspended print head and programmable automatic pressure adjustment system with pressure closed-loop feedback. Support on-line real time pressure feedback and automatic squeegee pressure balancing. Accurate pressure control ensures perfect forming effect of solder paste.
d) Programmable motor controls the squeegee demold speed and stroke from steel mesh, to realize multi-method demold.
e) Multi-functional PCB fixed positioning system, convenient and accurate PCB positioning.
f) Upward and downward visual positioning.
g) Built-in image processing system
h) Support 2D,SPC functions
- 2. Applicable pitches of Components
a) SMT Components such as resistors, capacitors, inductors, diode and triode: 0201, 0402, 0603, 0805, 1206 and other specifications;
b) IC: support SOP, TSOP, TSSOP, QFN packaging, min. pitch 0.3 mm; support BGA, CSP packaging, min. ball diameter of 0.2 mm;
c) Printing size:50mm x 70mm ~650 mm x 500 mm;
d) PCBThickness:0.8 mm ~ 6 mm
e) Thickness:thickness0.8 mm (excluding jig)
- 3. Applicable PCB Types
Applicable to PCB types of mobile phone, communication, LCD TV, STB, family cinema, vehicle electronics, medical power equipment, aerospace and aviation, besides general electronics products.
MPM SMT stencil PRINTER CHINA AGENT,MPM UP200 PRINTER
Printing with traditional screens, or with metal foil stencils, MPM Printers uniformly deposit solder paste, as well as masks, epoxies, adhesives, and other printable materials onto bare rigid or flexible PCBs in one of the key steps in the assembly process. MPM Printers print the solder paste that forms the physical and electrical connections for standard as well as fine and ultra-fine pitch components on today’s challenging, advanced electronic products for industrial, consumer, and military and aerospace uses.
MPM printers deliver superior results with today’s advanced metal foil stencils. Whether stencils are chemical or laser etched, conventional or stepped, standard or fine pitch, MPM printing technology with advanced-design metal squeegee blades or the EnclosedFlow™ print head achieves superior results with all electronic materials, from solder paste to silicones. Recognized worldwide for precision solder paste deposition on PCBs, MPM printers deliver fewer print defects and optimum aperture fill with the finest feature printing. Superb results are achieved with all types of solder paste, including lead-free and traditional tin/lead formulations, and all particle sizes for defect-free deposition and optimum aperture fill.
