SMT Screen automatic solder paste stencil Printer
Configuration:
1. Suspended print head with squeegee pressure automatic adjustment by direct-connected motor
a) Programmable automatic pressure adjustment system ensures accurate pressure control.
b) Pressures of front and rear squeegees are separately adjusted, to compensate pressure imbalance caused by fatigue deformation of squeegee to prevent from different printing quality in front and rear.
- 2. Standard stainless steel squeegee, unique design to improve the lifespan of squeegee blade.
- 3. Vision alignment system.
- 4. Table X/Y/θ automatic calibration system.
- 5. PCB clamping and support system:
- 6. NC slide way adjustment for conveyor width and speed.
- 7. Dry-type, wet-type or mixed combination of the two types for stencil cleaning system.
- 8. System Requirements: IPC (Industrial Personal Computer) with Windows XP System
- 9. Built-in software diagnosis system.ss
- 10. Standard SMEMA port.
i. General Introduction:
1. Product Functions:
Cp5 a high precision automatic solder paste screen printer designed for high precision screen printing or stencil printing in SMT industry.
2. Product Features:
a) Support wide spectrums of PCB sizes from 50mm x 50mm to 400mm x 340mm and PCB thickness from 0.6mm to 6mm.
b) High printing resolution:
- 1. High positional accuracy, repeated positioning accuracy ±0.01mm; printing accuracy 0.025mm
- 2. Support glue printing.
c) Automatic control improves production efficiency, quality control and saves production cost:
- 1. Automatic PCB calibration
- 2. Squeegee pressure adjustable
- 3. Automatic printing
- 4. Automatic stencil cleaning (dry-type and wet-type)
Items |
|
Parameter |
|
Repeat Position Accuracy |
±0.01mm(test data and method can be provided) |
||
Printing Accuracy |
±0.025mm(test data and method can be provided) |
||
Cycle Time |
<9s (Excluding Printing & Cleaning) |
||
Products Changeover |
<5Min |
||
Screen Stencil Size/Min |
470mm X 370mm |
||
Screen Stencil Size/Max |
737mm X 737mm |
||
Screen Stencil Size/Thickness |
20mm ~ 40mm |
||
PCB Size/Min |
50X50mm |
||
PCB Size/Max |
400X340mm |
||
PCB Thickness |
0.6~6mm |
||
PCB Warpage Ratio |
<1%(Based on diagonal length) |
||
Bottom of Board Size |
10mm |
||
Edge of Board Size |
3mm |
||
Transport Height |
900±40mm |
||
Transport Direction |
Left-Right; Right-Left; Left-Left; Right-Right |
||
Transport Speed |
100-1500mm/sec Programmable |
||
Board Location |
Support System |
Magnetic pin/Side support block/Flexible automatic pin(optional) |
|
Clamping System |
Elastic side clamping/ Elastic Z-direction tabletting (optional, but not suggested) |
||
Print head |
Direct-connected motor control of the squeegee pressure |
||
Squeegee Speed |
10~150mm/sec Programmable |
||
|
|||
Stencil Separation Speed |
0.01~10mm/sec Programmable |
||
Cleaning Method |
Dry-type, wet-type ( Programmable combination of the two cleaning methods) |
||
Table Adjustment Range |
X: ±4mm;Y:±6mm;θ:±2° |
||
Type of Image Fiducial Mark |
Standard geometry shape of fiducial mark, bonding pad / stencil hole |
||
Camera System |
Single digital camera with upward/downward vision system |
||
Air Pressure |
4~6Kg/cm2 |
||
Air Consumption |
Approx. 0.07m3 /min |
||
Control Method |
PC Control |
||
Power Supply |
AC:220±10%,50/60HZ 1Φ 1.5KW |
||
Machine Dimensions |
1220mm(L) x 1410mm(W) x 1550(H)mm (excluding the height of indicating lighthouse) |
||
Weight |
Approx:1000Kg |
||
Operation Temperature |
-20°C ~ +45°C |
||
Operation Humidity |
30%~60% |
||
