smt printer,pcb printer,PCBA PRINTER,SMT SOLDER PASTE PRINTER, SMT GULE PRINTER, smt stencil printer, smt screen printer
i. General Introduction:
1. Product Functions:
Cp5 a high precision automatic solder paste screen printer designed for high precision screen printing or stencil printing in SMT industry.
- 2. Product Features:
a) Support wide spectrums of PCB sizes from 50mm x 50mm to 400mm x 340mm and PCB thickness from 0.6mm to 6mm.
b) High printing resolution:
- 1. High positional accuracy, repeated positioning accuracy ±0.01mm; printing accuracy 0.025mm
- 2. Support glue printing.
c) Automatic control improves production efficiency, quality control and saves production cost:
- 1. Automatic PCB calibration
- 2. Squeegee pressure adjustable
- 3. Automatic printing
- 4. Automatic stencil cleaning (dry-type and wet-type)
d) Adopt company independently developed suspended print head with programmable pressure adjustment. Support on-line real time pressure feedback and automatic squeegee pressure balancing.
e) Programmable motor controls separation speed and distance among squeegee, stencil and substrate, to realize multi-method separation.
f) Multi-functional PCB positioning system for convenient and accurate PCB positioning.
g) Programmable PCB lifting platform ensure the PCB to lift to a proper height
h) Upward and downward visual positioning.
i) Built-in image processing system
- 3. Applicable pitches of Components
a) SMT Components such as resistors, capacitors, inductors, diode and triode: 0201, 0402, 0603, 0805, 1206 and other specifications
b) IC: support SOP, TSOP, TSSOP, QFN packaging, min. pitch 0.3 mm; support BGA, CSP packaging, min. ball diameter of 0.2 mm
c) Printing size:50mm x 50mm ~400 mm x 340 mm
d) PCBThickness:0.6 mm ~ 6 mm
e) FPCThickness:less than 0.6 mm (excluding jig)
- 4. Applicable PCB types
Applicable to PCB types of mobile phone, communication, LCD TV, STB, family cinema, vehicle electronics, medical power equipment, aerospace and aviation, besides general electronics products.
