Desktop Glue Dispensing Machine VB-300 and Glue Dispenser Robot
US$ 4,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
eta
Model Number:
VB 300
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Desktop Glue Dispensing Machine VB-300 and Glue Dispenser Robot for LensUS$ 4,000 - 20,000MOQ: 1 Set -
Glue Dispenser Robot for LED LensUS$ 4,000 - 20,000MOQ: 1 Set
-
Desktop Glue Dispensing Machine,glue Dispensing Robot for LensUS$ 4,000 - 20,000MOQ: 1 Set
-
Automatic Glue Dispensing Machine,glue Dispensing Robot for LensUS$ 4,000 - 20,000MOQ: 1 Set
-
Automatic Solder Paste Dispenser Machine for SmtUS$ 4,000 - 20,000MOQ: 1 Set
Place of Origin
China
Brand Name
eta
Model Number
VB 300
Ecnormic Desktop Glue Dispensing machine VB-300
Desktop Glue Dispensing machine VB-300 and glue dispenser robot
Product Description
VB Series three-axis dispenser uses a new visual positioning system in the industry, without the traditional computer systems, all operations will be integrated into self-developed handheld tablet computer, the equipment is simple, entire system, affordable, compact, simple, high performance.
Product Features
1 Imported brands stepper motor, timing belt; to ensure product stability and durability
2 Modular production and testing processes to ensure the accuracy of product consistency
3 Professional stable fluid control software that enables dispensing process better
3 Professional stable fluid control software that enables dispensing process better
4 Original path front panel display technology to ensure easy application
5 Easy and convenient user interface, easy to use
Recommended application
Consumer electronics, FPC soft board, PCB board,IC chip,Camera Module, VCM and other precision,dispensing, Phone hot melt adhesive coated frame.
Specification
| Specification | VB-series |
| Working area(mm) | VB-200: 140*140*75mm |
| VB-300: 240*240*75mm | |
| Precision accuracy(mm) | ±0.02 |
| Max speed(mm/s) | X-500,Y-500,Z-250 |
| Max. Acceleration(mm/s2) | 0.4g |
| Mechanical structure | H-bridge |
| Motion system | Step motor |
| Driving type | Timing belt |
| Dimension(mm) | VB-200: 400*320*478 |
| VB-300: 500*420*512 | |
| Z-axis loading | 3 kg |
| Work playing load | 6 kg |
| Programming | Touch screen teaching device |
| Memory | 256M |
| Vision system | Industrial CCD |
| Max power consumption | 300W |
| Input voltage | 220V/50HZ(±10%) |
| Resolution ratio | 0.011*0.011MM/PIXEL |
| Identification area | 7.1*5.3mm(chosen by camera lens) |
| Light source | LED light |
| Optional | No optional |
