high quality Micro-heated Regeneration absorption dryer
The features of the compressed air dryer
Control system use monolithic microcomputer program to automatic control, reliable and durable capacity. (PLC control can be selected)
With valve switch to automatic show, good human machine interface, easy to operate, it is convenient to maintain
Automatic alarm equipment, if the inlet temperature is too high, inlet pressure is too low or the heating temperature is too high (micro heat-regenerate type), the equipment will alarm
According to actual load and temperature, it can adjust the proportion of regenerate air consumption, save regenerate air energy consumption
It can select cycle switch time, satisfied the require of finished product dew point
A,B Absorb tower
A1,A2,B1,B2 Switch valve
5 Silencers
3,4,6,7 Check valve
8 Restrictor valve
9 Program controllers
10 Electric heaters
The introduction of the compressed air dryer
Air system
Eliminate channel flow phenomenon
The air distributor of absorb tower adopts large interface stainless steel diffuser and ensure that air flow can through the absorbent floor, avoid channel flow phenomenon, corrosion resistance, durability and never exchange
Install energy saving condition
According to dew point, inlet capacity, pressure, temperature, regenerate air flow can install energy saving condition. It can also depend on air dryer load, adjust regenerate air flow, and reach energy saving efficiency.
Heatless regenerate gas consumption less than 15%
Design of tower structure is rational, store 95%adsorpt heat. It is used to add regenerate air temperature, improve equipment desorbed capacity. Make regeneration of science thoroughly
The air source quality is stable
The direction of dry and regeneration are converse. The drier is not easy to pollute. The air source quality is stable
Micro heat regenerate adsorbed air dryer
Because of heater, decrease gas consumption to 6%
More than 80 cubic meters add reduced two pressure vent valves, one regenerate close valve, extend dryer life. If use molecular sieve as drier, it can reduce pressure dew point
Control system
Heatless: monolithic control (PLC control)
PLC microcomputer system control
Adopt Germany’s Siemens, it can automatic timing,automatic switch,display double tower work pressure and other function. It can through computer to remote control,alarm. Powerful function, safe and reliable control, system can be upgraded
Adsorb and dry time
Adsorb and dry time adopts pressure dew point control method, ensure air source quality (optional)
Detect exhaust temperature
According to exhaust temperature and humidity to determine regenerate time, in regenerate effect condition, to switch and reduce regenerate gas consumption to minimum. Avoid overtime gas consumption and high efficiency (optional)
Pressure equalization failure alarm
Two tower use pressure equalization to protect switch. If pressure equalization failure, will alarm (optional)
Trouble signal alarm
All pneumatic valves with position switch, when have trouble, system will send alarm signal (optional)
Air control system
Control air road
Control air road use brass preparation, work life is long, without exchange.(optional)
Compressed heat regenerate type dryer
