Features
Photo detector and preamplifier in one package
Internal Bandfilter for PCM frequency
Internal shielding against electrical field
disturbance
TTL and CMOS compatibility
Output active low
Special Features
Data rate 20 kbit/s
Small size package
Supply voltage 2.7 – 5.5V
Short settling time after power on
High envelope duty cycle can be received
Enhanced immunity against disturbance
from energy saving lamps
Recommendation for Suitable Data Formats
The circuit of the TSOP7000 is designed in that way that disturbance signals are identified and unwated output
pulses due to noise or disturbances are avoided. A bandpassfilter, an automatic gain control and an integrator
stage is used to suppress such disturbances. The distinguishing marks between data signal and disturbance
are carrier frequency, burst length and the envelope duty cycle.
The data signal should fullfill the following conditions:
The carrier frequency should be close to 455kHz.
The burstlength should be at least 22s (10 cycles of the carrier signal) and shorter than 500s.
The separation time between two consecutive bursts should be at least 26s.
If the data bursts are longer than 500s then the envelope duty cycle is limited to 25%.
The duty cycle of the carrier signal (455kHz) may be between 50% (1.1s pulses) and 10% (0.2.µs pulses).
The lower duty cycle may help to save battery power.
Devices
The infrared receiving head is widely used in: air conditioning, fan, heater, humidifier, TV, DVD, set-top boxes, mobile DVD, hard disk player, multimedia audio, digital photo frame, mobile phone and other home appliance products, computer and peripheral equipment, induction sanitary ware, instrumentation, industrial automation, remote control toys, communication equipment, photographic equipment, office machines, financial electronic, automotive electronics, lighting and other fields.
| Part number | Product Image | Package | Dimensions (mm) | Carrier Frequency (kHz) | AGC | Type | Transmission Distance Typ. (m) | Detection Threshold / Sensitivity Typ. | Viewing Angel (°) | Supply Current Typ. | Pinning |
| TSOP32S40F | Enlarge | Mold | 6.0 W x 6.95 H x 5.6 D | 40 | AGC-S | 45 | 0.08 | ± 45 | 0.35 | 1 = OUT, 2 = VS, 3 = GND | |
| TSOP34S40F | Enlarge | Mold | 6.0 W x 6.95 H x 5.6 D | 40 | AGC-S | 45 | 0.08 | ± 45 | 0.35 | 1 = OUT, 2 = GND, 3 = VS | |
| TSOP37S40H | Enlarge | Belobog shield | 4.3 W x 4.3 H x 1.0 D | 40 | AGC-S | 45 | 0.12 | ± 75 | 0.35 | 1 = OUT, 2, 3, 6, 7, 8 = GND, 4, 5 = VS | |
| TSOP75S40F | Enlarge | Heimdall | 6.8 W x 3.0 H x 3.2 D | 40 | AGC-S | 45 | 0.12 | ± 50 | 0.35 | 1, 4 = GND, 2 = VS, 3 = OUT | |
| TSOP75S40FW | Enlarge | Heimdall no lens | 6.8 W x 3.0 H x 3.2 D | 40 | AGC-S | 30 | 0.25 | ± 75 | 0.35 | 1, 4 = GND, 2 = VS, 3 = OUT | |
| TSOP37S40 | Enlarge | Belobog | 3.95 W x 3.95 H x 0.8 D | 40 | AGC-S | 45 | 0.12 | ± 75 | 0.35 | 1 = OUT, 2, 3, 6, 7, 8 = GND, 4, 5 = VS | |
| TSOP31130 | Enlarge | Cast | 10.0 W x 12.5 H x 5.8 D | 30 | AGC1 | 45 | 0.12 | ± 45 | 0.35 | 1 = GND, 2 = VS, 3 = OUT | |
| TSOP32130 | Enlarge | Mold | 6.0 W x 6.95 H x 5.6 D | 30 | AGC1 | 45 | 0.08 | ± 45 | 0.35 | 1 = OUT, 2 = VS, 3 = GND |
Manufacturer Part Number: |
TSOP7000LL1(Vishay) |
Manufacturer / Brand: |
Vishay |
Quantity Available: |
340000 (Please contact us to confirm the available quantity) |
Unit Price: |
Contact us |
D/C (Date Code): |
Generally newest 2014+ |
Lead Time (Delivery Time): |
IN STOCK, Fast delivery |
Condition: |
NEW AND UNUSED, ORIGINAL FACTORY PACKING |
Package / Case: |
VSOP/Belobog/Belobog Shield/Heimdall No-lens/Heimdal/Panhead/Mold/Minicast/Cast |
Packaging: |
Factory sealed packing |
SPQ (Standard Package Quantity): |
Contact us |
MOQ: |
100Piece |
Datasheet Download: |
Contact: winwin-ke@hotmail TradeManager:winchips /skype:win-chips |
