High Strength Pultruded FRP Grating, Fiberglass Floor Grating

High Strength Pultruded FRP Grating, Fiberglass Floor Grating thumbnail-1
High Strength Pultruded FRP Grating, Fiberglass Floor Grating thumbnail-2
High Strength Pultruded FRP Grating, Fiberglass Floor Grating photo-1
High Strength Pultruded FRP Grating, Fiberglass Floor Grating photo-2
US$ 3 - 4.5 MOQ: 500 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
yalong
Model Number:
Pultruded FRP Grating
Contact Supplier Request Quote Chat Now
Zhengzhou Yalong Pultrex Composite Materials Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name yalong
Model Number Pultruded FRP Grating
Application decking, flooring, platform support beams
Surface Treatment as customer require
Technique pultrusion fiberglass grating
Dimensions as customer require

High Strength Pultruded FRP Grating, fiberglass floor grating



FRP grating, pultruded frp grating, fiberglass grating, frp pultrusion grating, trench grating, drain grating, grating walkway, platform grating





1-25mm,38mm, 40mm, 50mm,58mm,65mm high grating are available;



2-Easy to install;



3-Can be cut at any lengths you need; open area is decided by customer



4-Grating clamps are available.





Pultruded FRP Grating is built with a much stronger process, and can carry a far superior load, and handle much greater impacts than molded grate

Porpular for corrosive environment, or require electric non-conductive place



fiberglass grating applications including:


  •  Railing Systems
  •  Fencing Systems
  •  Decking and Walkways
  •  Gates
  •  Rooftop Structures
  •  Large Trellis Structures
  •  Rooftop HVAC and Antenna Screens
  •  Residential Home Columns
  •  Bridges
  •  Waterpark Structures
  •  Docks and Piers





Pultruded FRP Grating specification list:



High Strength Pultruded FRP Grating, fiberglass floor grating



 Fiberglass grating features

High Strength Pultruded FRP Grating, fiberglass floor grating





Below project is one electric substation flooring supports system, take use frp angle beam and frp rectangular beam

 High Strength Pultruded FRP Grating, fiberglass floor grating

High Strength Pultruded FRP Grating, fiberglass floor gratingHigh Strength Pultruded FRP Grating, fiberglass floor grating

High Strength Pultruded FRP Grating, fiberglass floor grating High Strength Pultruded FRP Grating, fiberglass floor grating





Why Pultruded FRP fence:

Mechanical Properties of Pultruded Profiles Vs. Other Structural Materials



Mechanical Properties Pultruded FRP Rigid PVC Mild Steel Stainless Steel Wood
Tensile Strength
(N/mm2)		 382 44 340 340 80
Flexural Strength
(N/mm2)		 468.3 70 380 380 12
Flexural Modulus
(N/mm2)		 22489 2400 196000 196000 700
Izod Impact
(N/mm2)		 2.15 0.09 1.5 0.53 -







  Physical & Chemical Properties of Pultruded Profiles Vs. Other Structural Materials

Mechanical Properties Pultruded FRP Rigid PVC Mild Steel Stainless Steel Wood
Specific Gravity 1.8 1.38 7.8 7.92 0.52
Thermal Conductivity
(Kcal/hr/m2/ C)		 24.4 6.4 1220 732 0.4
Coeff. of Linear Expansion
(cm/cm C) x 10-6		 5.2 37 8 10 1.7
Safe Working Temp.  °C 130 55 600 600 160
Flame Resistance Good* Poor Excellent Excellent Poor
Corrosion Resistance
a. Acidic Excellent Good Poor Excellent Poor
b. Alkaline Good Fair Good Excellent Poor
c. Solvents Fair Poor Good Excellent Fair
d. Coastal environment Excellent Good Poor Excellent Fair
e. Outdoor Exposure Excellent Poor Fair Excellent Fair
f. Effluent Water Excellent Good Poor Excellent Fair
g. Steam Good Poor Fair Excellent Fair



Yalong Pultrusion fiberglass profile including:

fiberglass rod, round tube, channel, angle, I beam, square & rectangular tube, window frame, shutter blade, other structural profile, etc.
Above profile generally be assembled to:
Structural shapes
Fiberglass window and shutter
Pultruded Fiberglass Grating
Guardrail handrail fence
Insulation ladders and stairs
Tool handle
Cooling tower components
filler supports, anti-freeze board, grating walkway
Structure and support



Yalong fiberglass pultrusion profile other applications(below all photo belong to Yalong except last one)
