1.Product Application
For carrying natural gas,petroleum,etc.on sea floor.
2.Specification
| Hose size | Inside Diameter | Reinforcement Diameter | Outside Diameter | Working Pressure | Proof Pressure | Burst Pressure | Min.Bend | Weight Kg/m | ||||||
| mm | mm | mm | MPa | MPa | Mpa | Radius | ||||||||
| MPa | Psi | MPa | Psi | Mpa | Psi | mm | ||||||||
| 2sp-152-8 | 152±2.0 | 173±3.0 | 179±4.0 | 8 | 1160 | 12 | 1740 | 16 | 2320 | 2280 | 18 | |||
| 2sp-203-8 | 203±2.0 | 223±3.0 | 230±4.0 | 8 | 1160 | 12 | 1740 | 16 | 2320 | 3050 | 24 | |||
| 2sp-254-8 | 254±2.0 | 275±3.0 | 282±4.0 | 8 | 1160 | 12 | 1740 | 16 | 2320 | 3810 | 30 | |||
| 2sp-305-8 | 305±2.0 | 330±3.0 | 338±4.0 | 8 | 1160 | 12 | 1740 | 16 | 2320 | 4510 | 36 | |||
| 4sp-152-16 | 152±2.0 | 184±3.0 | 192±4.0 | 16 | 2320 | 24 | 3480 | 32 | 4640 | 2580 | 24 | |||
| 4sp-203-16 | 203±2.0 | 236±3.0 | 243±4.0 | 16 | 2320 | 24 | 3480 | 32 | 4640 | 3350 | 31 | |||
| 4sp-254-16 | 254±2.0 | 285±3.0 | 292±4.0 | 16 | 2320 | 24 | 3480 | 32 | 4640 | 4110 | 39 | |||
| 4sp-305-16 | 305±2.0 | 341±3.0 | 350±4.0 | 16 | 2320 | 24 | 3480 | 32 | 4640 | 4810 | 47 | |||
1.Advanced equipment and test instruments.
2. Quality first,supremacy service.
3.Well-built system of management.
How many days that you could finish an order of 20 foot container?
Generally speaking, if you order our regular products that exactly the same with our catalog, we could finish your order of 20' container within 30 days after receiving your deposit or L/C.
What's your payment term?
T/T 30% deposit in advance, T/T the balance against the fax of original bill of lading , L/C at sight , D/P at sight , West union
What's trade term that your quotations base on? FOB, CIF or CFR?
1) FOB, free on board.
2) CIF, cost insurance freight
Which Chinese port that you usually delivery the goods ?
xingang Port
Where your products are mainly sold?
Our products have shipped around the world, Brazil,Chile,Peru,Argentina ,Spain, Russia, USA, etc.
How about your service?
We have good and professional team
Any small problems will be solved at the most prompt time.
We always offer quick response, all your inquire will replied within 24 hours.
If you are interested in our products, please do not hesitate to contact with us, we will offer our price to you as soon as possible.
