Help CenterChina Best Quality 6 Ton Road Rescue Vehicle With Crane
Related Products
-
China Best Quality 8*4 Rescue Vehicle Heavy WreckerUS$ 1 - 100,000MOQ: 1 Set -
China Best Quality Multifunction 2 Ton Wrecker TruckUS$ 20,000 - 80,000MOQ: 1 Set
-
6*4 Road Repair Car 8ton With Optional ChassisUS$ 1 - 100,000MOQ: 1 Set
-
China Best Quality Foton 10 Ton Wrecker for Emergency RescueUS$ 1 - 100,000MOQ: 1 Set
-
China Best Quality 5ton Road Block Removal Truck for Hot SaleUS$ 1 - 100,000MOQ: 1 Set
Road wrecker | ||||
Model |
Road wrecker |
Dimension |
9500*2500*3550,3600(mm) |
|
Chassis type |
ZZ1256M4646C (optional) |
Cargo body size |
XX |
|
Total mass |
25000 (kg) |
Appearance / departure angle |
15/14(°) |
|
Rated payload |
5000(Kg) |
F/R suspension |
1560/1990 (mm)
|
|
Kerb weight |
19880 (kg)
|
Maximum speed |
90(km/h) |
|
Engine |
WD615.92/WD615.93/WD615.92E/WD615.93E |
|||
Displacement |
9726/9726/9726/9726(ml) |
Power |
196/213/196/213 (kw) |
|
Manufacturer |
China Heavy Duty Truck Group Co., Ltd. / |
|||
Emission standard |
GB17691-2005,GB3847-2005 |
|||
Number of the axles |
3 |
Front tread |
1939,1958 (mm) |
|
Wheel base |
4325+1350,4600+1350(mm)
|
Rear tread |
1800,1830 (mm) |
|
Number of the tires |
10 |
Tire type |
11.00-20,12.00-20 |
|
Fuel type |
Diesel |
Number of the springs |
9/12,10/12 |
|
Axle load |
4325+1350,4600+1350 |
Cab Passengers |
2 |
|
Notes |
Lift Quality: 4990kg; with the chassis, optional high-roof cab Steyr Wang Overall height when the size of 3600mm. My Wrecker production plants can be divided into separate prop hanging type, body care hanging together, flat back set type, platform type lift. Separate Hanging care and the care that the crane arm can be working alone, independently of each other; care body lift in conjunction with the care that the crane arm linked together; flat-type back contains hanging through traction or vehicle to give back on a plate containing transport; platform-type lift platform, moving through the lift pass or high-altitude operations. According to Wrecker's crane, corbel-specific functions, can be divided into Wrecker crane rotary type, slide-type crane to shore up arm folding (load) type and so on. Wrecker with assisted steering, mainly used in tunnels, bridges and other venues operating on limited occasions. |
|
||
Hubei Haotian Special Automobile Co., Ltd is specialized in manufacture and marketing of different special automobiles. We are a group management company, and established the wholesome system of manufacture and marketing by the way of joint venture, holding, participation to integrate the resources of the industry. We are successively in the way of joint venture, holding, participation with Hubei Haotian Special Automobile Co., Ltd, Hubei Lutong Special Automobile Co., Ltd, Haotian in Hongkong Special Automobile Co., Ltd. In order to Expand the overseas market, we established the overseas sales and service channel to engage in the trade and investment of overseas sales channel.
The company employ over 1,000 staffs, have a strong technology R&D team and owns plasma cutting machines, plasma screwing machines, large-scale computerized numerical control plate bending machine, automatically welding machines, goliath carling welding machine, cylinder automatic welding machine, cylinder welding special tooling machine, drum equipment ,blade forming mould and so on, more than 300 advanced production equipments .Main products are: road wrecker truck, concrete mixer truck, oil tanker truck, chemical liquid delivery truck, bulk powder delivery truck, crane truck, aerial operation truck, rescue truck ,emergency fire truck, fire sprinkler truck, semi-trailer, sanitation garbage truck, water truck, etc. In order to meet the requirements from different industries, we have been developed the pressure vessel, aluminium tanker, high technology sanitation truck and small construction machinery.
