Heat Pump Driers for Agriculture
PHNIX HEAT PUMP DRYERS FOR AGRICULTURE
PHNIX Heat Pump Dryers for Agriculture run safely and efficiently with high temperature scroll compressor. The environmentally-friendly R134a refrigerant helps the units provide drying temperature as high as 80oC. They are designed for many industrial uses such as tobacco leaf drying, food drying, herbs drying, woods drying etc.
Efficient Heat Recovery
Modular Design
FEATURES
1) Efficient heat recovery
During the exchange between the fresh air and the exhaust air, waste heat from the drying room will be collected again. The absorbing rate can reach 70%.
2) Modular design
Modular design of the units makes the compatiblity of drying rooms and the units’ pieces more flexible. At the same time,transportation, installation and disassembling will also become a lot more simple.
CERTIFICATIONS
CE, CB, EC, ETL, CETL, C-TICK, WATER MARK, STANDARD MARK, UL, SABS, SANS, SAA, SASO, VDE, RoHS, REACH, NF414, EN14511-2:2011, AHRI, ISO9001, ISO14001, Six Sigma, Lean Production and Management
| Model | PAXHZ | 060S | 120S |
| Heating capactiy | kW | 18.0 | 36.0 |
| Compressor power input | kW | 4.2 | 8.4 |
| Fan motor power input | kW | 1.8 | 3.6 |
| Running Current | A | 10.8 | 21.6 |
| Power supply | V/Ph/Hz | 380/3/50 | 380/3/50 |
| Compressor type | / | Scroll | Scroll |
| Temperature control accuracy | ℃ | ±1 | ±1 |
| Compressor Qty | PCS | 1 | 2 |
| Cycle air volume | m3/h | 7500 | 15000 |
| The maximum air outlet temp. | ℃ | 80 | 80 |
| Refrigerant | / | R134a | R134a |
| heating Recovery capacity | kW | 12.5 | 25.0 |
| Power input for recovery | kW | 0.45 | 0.8 |
| fresh air volume | m3/h | 1300 | 2500 |
| Dehumidification capacity | kg/h | 25.5 | 49 |
| Noise | dB(A) | 62 | 65 |
| Operation Range | ℃ | 5 to 43 | 5 to 43 |
| Net Dimensions(L/W/H) | mm | 1670×850×3500 | 1670×1610×3500 |
| Dimensions of air return part(L/W/H) | mm | 900×800×1750 | 1530×900×1750 |
| Dimensions of heating part(L/W/H) | mm | 1720×830×1360 | 1720×830×1360 |
| Dimensions of heating recovery part(L/W/H) | mm | 1720×830×910 | 1720×1650×910 |
| Net weight | kg | 435 | 763 |
| Shipping weight | kg | 537 | 973 |
