Help CenterAuto Hot Stamping Machine
US$ 43,000 - 44,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, hot stamping
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Folder Gluer(gluer Machine,pasting Machine)US$ 10,000 - 12,000MOQ: 1 Set -
LaminatorUS$ 480 - 600MOQ: 1 Set
-
Paper Cutting MachineUS$ 580 - 980MOQ: 1 Yard
-
Glue Binding Machine (Wireless Binding Machine, Binding Machine)US$ 1,400 - 1,500MOQ: 1 Set
-
Foil Slitter (hot Stamping Foil Slitter, Foil Cutter).US$ 285 - 320MOQ: 1 Piece
Condition
New
Plate Type
Other, hot stamping
Place of Origin
Shanghai, China
Brand Name
Diamond
Model Number
780
Usage
Card Printer, Cloths Printer, Paper Printer, Other, Card Printer, Cloths Printer, Paper Printer, Paper Forming Machine
Automatic Grade
Automatic
Voltage
220V
Gross Power
2KW
Dimensions(L*W*H)
950mm*620mm*1610mm
Weight
500kg
Certification
CE SGS
After-sales Service Provided
Engineers available to service machinery overseas
- The780 Automatic Foil Stamping and Die Cutting Machine is designed for the Hot Stamping, Die Cutting, Pressing Convex and Creasing etc technics, it’s suitable for paper, cardboard, plastic film and so on. It can finish feeding, die cutting, collecting work cycle automatically.
- The machine is composed of four parts: main motor, hot stamping, auto feeder and electric equipment. The motor’s main transmission is by bend shaft structure driving the platen running up and down, plus the pressure adjusting structure, coordinate to finish hot stamping or die cutting job.
- The electrical parts are composed of main motor control, feeder/collect control and foil feeder control and so on. The whole machine is controlled by micro processor.
- The machine is equipped with the automatic lubrication system.
Specifications:
Model |
780 |
Max. sheet size(mm) |
780×560 |
Min. sheet size(mm) |
280×220 |
Max. feeding pile height (mm) |
800 |
Max. collect pile height (mm) |
160 |
Max. working pressure(N) |
110×104 |
Power rating(KW) |
12 |
Air pump displacement(m3/h) |
40 |
Paper range(g/m2) |
100 -2000 |
Max. mechanical speed (s/h) |
1500s/h paper<150g/m2 2500s/h paper>150g/m2 |
Machine weight(kg) |
4300 |
Machine noise(db) |
<81 |
Heating capacity(KW) |
8 |
Overall machine dimensions(mm) |
2700×1820×2020 |
