Help CenterAutomatic High-Speed Slotter Machine
Related Products
-
Corrugated Carton Box Slotting MachineUS$ 5,000 - 6,000MOQ: 1 Set -
KFQ4860 Corrugated Carton Slotter MachineUS$ 6,000 - 7,000MOQ: 1 Set
-
KFQ8060 Series Of Slotting MachineUS$ 7,500 - 12,000MOQ: 1 Set
-
KFQ7060 Corrugated Carton Slotting MachineUS$ 7,500 - 8,900MOQ: 1 Set
-
Slotting Machine for Corrugated Carton MachineUS$ 6,000 - 7,000MOQ: 1 Set
1. Parameters
ZKFQ4810 Series Of Automatic High-speed Slotting Machine | |||
Wyazs name |
Unit |
2900 |
2700 |
Max paper coverage |
mm |
1500*2850 |
1500*2650 |
Skip feed paper size |
mm |
1850*2850 |
1850*2650 |
Min finish size |
mm |
400*500 |
400*500 |
Machinable cardboard thickness |
layers |
2-12 |
2-12 |
Slot width |
mm |
7.0 |
7 |
Cut corner deepness |
mm |
50 |
50 |
Max.depth of slot |
mm |
400 |
400 |
Max speed |
Pcs/min |
120 |
120 |
Economy speed |
Pcs/min |
80-100 |
80-100 |
Slotting precision |
mm |
±1.5 |
±1.5 |
Frequency conversion power of main motor |
kw |
11 |
11 |
2.Function and characteristic
1.This machine is the one-off finished high efficiency equipment which cardboard press line,mend margin,cut corner.
2.Adopts vacuum assistant absorb paper system,set grade adjust suction,let flexual cardboard automaitic entered.
3.Slot blade phase adopt 360 degree electric position and negative turn slightly adjust,blade axes processed by rigidity chroming electroplate,andnicety grinding,firmness durable.
4.Gear lubricate,adopt spout out style cyc.Reduce noise,prolong gear using life.
5.Adopts hackle blade
6.Can matched puching equipment.
