Carton Thin Edge Slitter& Creasing Machine hin Blade Slitter and Scorer

US$ 6,000 - 8,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Other, carton making machine

Packaging Type:

Cartons

Dongguang Canghai Packing Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other, carton making machine

Packaging Type Cartons

Packaging Material Wood

Automatic Grade Semi-Automatic

Driven Type Electric

Voltage 220v/380v/440v

Power 4KW

Dimension(L*W*H) 2630x1791x1130

Certification CE IAF

After-sales Service Provided Engineers available to service machinery overseas

vided to corrugated paperboard production line

ntrol easily. Creasing line without crack

3.Sharp blade edge 4.CE

Product Description

BFY Series Thin Knife Paperboard Slitting and

Creasing Machine

machinery introduction

1Pre-pressing paper feeding type, smoothly;

2Thin knife slitting, thickness of the blade: 1mm;

3Grind the blade edge with grindstone in two methods: automatically or manually;

4Sharp blade edge can slit the cardboard smoothly and neat.

5Work process: Pre-pressing, slitting and creasing. Creasing line without crack

6The machine can be provided to corrugated paperboard production line.

Parameter	Unit	Model
Parameter	Unit	BFY-2000	BFY-2500
Feeding width	mm	2000	2500
Max. speed	m/min	150	150
Slitting blade	piece	3-5	3-5
Min. Separate slitting width	mm	200	200
Min. creasing width	mm	200	200
External diameter of thin & round blade	mm	260	260
Thickness of thin & round blade	mm	1	1
Power	kw	4	4
Weight of machine	kg	2000	2500
Exterior dimension	mm	2630x1791x1130	3050x1791x1130
