Function :
The machine is used for the small and middle carton factory . it us used for the final process working produce . simple operation . solid binging , little noise . the machine speed 5-10 times as fast as the stapler machine .
- 1. worktable
the worktable can go up and down by photoelectric control , increase the work efficiency .
- 2. press and revise
1) the carton is agglutinate by second press after the carton is gelatinized
2) the machine can auto revise , the carton size is exact . shun the carton glue unit have the superposition .
3) the fan have the air-dry function .
4) the machine can auto counter , the machine have the rlatn photoelectric , the carton can auto export when the carton arrive to the set number .
Main Technical parameter
Max size carton length |
2800mm |
|||
Min size carton length |
600mm |
|||
Max size carton height |
1515mm |
|||
Min size carton height |
250mm |
|||
Carton worktable height |
900mm |
|||
Power |
4kw |
|||
Speed |
40 piece/min |
|||
Weight |
2000kg |
|||
Volume |
3800*1800*1700mm |
|||
main motor |
kw |
4 |
||
