Home > Packaging & Printing > Packing Machinery > Gluing Machine > Automatic Glue Machine / Carton Box Folding and Gluing Equipment / Auto Folding and Auto Glueing
Automatic Glue Machine / Carton Box Folding and Gluing Equipment / Auto Folding and Auto Glueing
US$ 10,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Speed Automatic Glue Machine/paper Glue Fold Machines/folding Glue MachineUS$ 10,000 - 20,000MOQ: 1 Set -
High Speed Automatic Glue Machine/gluing Machine/folding Glue MachineUS$ 10,000 - 20,000MOQ: 1 Set
-
Packaging Machine ZXJ Series High Speed Automatic Glue MachineUS$ 10,000 - 20,000MOQ: 1 Set
-
Automatic Fold Box Glue Machine/Gluing Machine/automatic Gluer/automatic Folding Carton Box Gluing MachineUS$ 20,000 - 35,000MOQ: 1 Set
-
Automatic Fold Box Glue Machine/Gluing Machine/automatic GluerUS$ 20,000 - 35,000MOQ: 1 Set
Condition
New
Application
Other, Machinery & Hardware
Packaging Type
Cartons
Packaging Material
Paper
Automatic Grade
Automatic
Driven Type
Electric
Power
6KW
Place of Origin
Christmas Island
Brand Name
canghai
Model Number
ZXJ automatic
Dimension(L*W*H)
15m*4m*1.5m
Weight
2200kg
Certification
iso 9001:2000
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
automatic folding and gluing machinemax speed : 150 pieces/min
second creasing
vacuum adsorption feeding
CE certificate
- Technical specifications:
Model | ZXJ-2400 | ZXJ-2800 |
Max.Cardboard(mm) | 900*2200 | 1200*1600 |
Mini.Cardboard(mm) | 300*900 | 300*900 |
Dimensions(mm)(L*W*H) | 11000*3000*1600 | 12500*3400*1600 |
Total weight | 6000kg | 7000kg |
Power Reduired | 11.5kw 380v 3 phase 50Hz | 14.5kw 380v 3phase 50Hz |
Paperboard thickness | 35 plaer paperboard | |
control | PCL & Touch screen | |
Function and unit :
ZXJ series auto glue machine is made of vacuum feeder unit , glue and fold unit , counter and stacker unit . frequency conversion motor with quality inverter adjust speed . PLC and touch screen control system for easy operation and running stable . average speed 150picecs/min . energy consevation and high speed , saving labor cost .
Feeder unit :
- vacuum unit feeder to feed warping cardboard easily
- Quality electromagnetic clutch and brake adopted ,feeder unit control solely , easy operation .
- scorer wheel adjust the cardboard thickness 2—5mm
- second creasing unit used for the cardboard which was not crease well
Glue unit :
- simple unit and high reliability , glue quantity adjust , cleaning easily.
- stainless steel glue wheel adopted , long life and saving glue cost
- imported quality rubber belt adopted , auto folder
- with cardboard rectify device and creasing rectify device
Counter
- stacker and counter are simple and reliable
- digital control ,operation easily and reliable , no stop put in data and auto counter
- with rectification function
- cardboard counter and put out by pneumatic stable and quickly /
