MPO singlemode fiber optic connector for CCTV and telecomunication
Specification:
Material: Zirconia (ZrO2) ferrule
Insertion loss: <0.2dB
Return loss: >65dB
Service life: >1000 times
Temperature range: -40° ~85°
Features:
1) Superior qualified standard polishing;
2) 100% optic test: Insertion Loss: ≤0.3 (PC); ≤0.2 (APC); ≤0.2 (UPC); ≤0.3 (SPC);
3) 100% optic test: Return Loss: ≥45 (PC); ≥60 (APC); ≥55 (UPC); ≥50 (SPC);
4) φ0.9mm, φ2.0mm, φ3.0mm cable optional
5) Simplex and duplex connector available;
6) Good exchange ability and good durability;
7) Available in fiber bunch, ribbon fan-out, pigtail available;
8) Meets ISO9001, ROHS and Bell core GR 326-core standards;
9) Customized specifications are welcomed.
Application:
Telecommunication
CATV
LAN (including FITL, FTTH and FTTD)
Data network
Performance Index
Parameter |
Unit |
FC,LC,SC |
ST,MU,SMA905 |
MTRJ,MPO |
|||||||
SM |
MM |
SM |
MM |
SM |
MM |
||||||
PC |
UPC |
APC |
PC |
PC |
UPC |
PC |
PC |
UPC |
PC |
||
Insertion loss(typical) |
dB |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
Return loss |
dB |
≥45 |
≥50 |
≥60 |
≥30 |
≥45 |
≥50 |
≥30 |
≥45 |
≥50 |
≥35 |
Operating wavelength |
nm |
1310,1510 |
1310,1510 |
1310,1510 |
|||||||
Exchangeability |
dB |
≤0.2 |
≤0.2 |
≤0.2 |
|||||||
Vibration |
dB |
≤0.2 |
≤0.2 |
≤0.2 |
|||||||
Operating temperature |
°C |
-40~+75 |
-40~+75 |
-40~+75 |
|||||||
Storage temperature |
°C |
-45~+85 |
-45~+85 |
-45~+85 |
|||||||
Cable diameter |
mm |
Φ3.0,Φ2.0,Φ0.9 |
Φ3.0,Φ2.0,Φ0.9 |
Φ3.0,Φ2.0,Φ0.9 |
|||||||
FAQ
Q1: What is your main products?
A; Our main products are fiber patch cord, fiber pigtail, fiber cable and its related products.
Q2: Are you a trading company or manufacture?
A: We are a factory.
Q3: How can i get some samples?
A: We are honored to offer you some FREE samples under $20.00 for testing, but buyer should bear the shipping costs.
Q4: Can you supple the OEM products under our brand ?
A: Yes, sure. We could supply OEM products with the package, but need MOQ to print your brand
Q5: Can we become your distributor or agency in our area?
A: Yes, it's possible to become our distributor or agency in your area after several orders in a period of time.
