3.05 mm galvanized steel wire for ACSR/ zinc coated steel wire/high carbon tensile steel/ armouring wire
1. Product specifications
Steel Grade GB Standard | Carbon % | Silicon % | Manganese % | Phosphorus % | Sulphur % | Chromium % |
60# | 0.60-0.61 | 0.18-0.22 | 0.52-0.59 | 0.012 | 0.007 | 0.06-0.07 |
65# | 0.65 | 0.21 | 0.56 | 0.013 | 0.008 | 0.05 |
65Mn | 0.60-0.70 | 0.10-0.25 | 0.70-1.00 | 0.030 | 0.030 | 0.20 |
70# | 0.69-0.71 | 0.19-0.21 | 0.53-0.58 | 0.010-0.012 | 0.003-0.006 | 0.01-0.05 |
72A 72B | 0.72 | 0.19 | 0.71 | 0.013 | 0.006 | 0.02 |
80# | 0.80-0.81 | 0.22-0.24 | 0.59-0.76 | 0.008 | 0.004 | 0.04 |
82A 82B | 0.82 | 0.24-0.25 | 0.76-0.77 | 0.011-0.014 | 0.004-0.007 | 0.17-0.17 |
Tensile Strength:
Steel Grade GB Standard | Carbon % | Silicon % | Manganese % | Phosphorus % | Sulphur % | Chromium % |
60# | 0.60-0.61 | 0.18-0.22 | 0.52-0.59 | 0.012 | 0.007 | 0.06-0.07 |
65# | 0.65 | 0.21 | 0.56 | 0.013 | 0.008 | 0.05 |
65Mn | 0.60-0.70 | 0.10-0.25 | 0.70-1.00 | 0.030 | 0.030 | 0.20 |
70# | 0.69-0.71 | 0.19-0.21 | 0.53-0.58 | 0.010-0.012 | 0.003-0.006 | 0.01-0.05 |
72A 72B | 0.72 | 0.19 | 0.71 | 0.013 | 0.006 | 0.02 |
80# | 0.80-0.81 | 0.22-0.24 | 0.59-0.76 | 0.008 | 0.004 | 0.04 |
82A 82B | 0.82 | 0.24-0.25 | 0.76-0.77 | 0.011-0.014 | 0.004-0.007 | 0.17-0.17 |
Tensile Strength:
High Carbon Spring Steel Wire | ||||
Diameter(mm) | Tensile Strength ( Mpa ) | |||
SL type | SM type | DM type | SH type | |
0.30 |
| 2307-2650 | 2370-2650 | 2660-2940 |
0.40 |
| 2270-2550 | 2270-2550 | 2560-2830 |
0.50 |
| 2200-2470 | 2200-2470 | 2480-2740 |
0.60 |
| 2140-2400 | 2140-2400 | 2410-2670 |
0.70 |
| 2090-2350 | 2090-2350 | 2360-2610 |
0.80 |
| 2050-2300 | 2050-2300 | 2310-2560 |
1.00 | 1720-1970 | 1980-2220 | 1980-2220 | 2230-2470 |
1.20 | 1670-1910 | 1920-2160 | 1920-2160 | 2170-2400 |
1.40 | 1620-1860 | 1870-2100 | 1870-2100 | 2110-2340 |
1.60 | 1590-1820 | 1830-2050 | 1830-2050 | 2060-2290 |
1.80 | 1550-1780 | 1790-2010 | 1790-2010 | 2020-2240 |
2.00 | 1520-1750 | 1760-1970 | 1760-1970 | 1980-2200 |
2.50 | 1460-1680 | 1690-1890 | 1690-1890 | 1900-2110 |
3.00 | 1410-1620 | 1630-1830 | 1630-1830 | 1840-2040 |
4.00 | 1320-1520 | 1530-1730 | 1530-1730 | 1740-1930 |
5.00 | 1260-1450 | 1460-1650 | 1460-1650 | 1660-1830 |
6.00 | 1210-1390 | 1400-1580 | 1400-1580 | 1590-1770 |
7.00 | 1160-1340 | 1350-1530 | 1350-1530 | 1540-1710 |
8.00 | 1120-1300 | 1310-1480 | 1310-1480 | 1490-1660 |
2.Application
can be used to make brush, spring,gabion,fence and so on
3.Professional QC inspection
4.Factory Scene
5.Workshop
6. Loading the product
7.Exhibition Scene
8. ISO certificates and International standard
9.Contact Method
We are sincere and welcome your inquiry! Hope we can help you !
Contact person:Mia
Mobile:0086-18768012141
helitingmia(@)
Skype:helitingmia
