CCZK MINI Magnetron Sputtering Vacuum Coating Machine

CCZK MINI Magnetron Sputtering Vacuum Coating Machine thumbnail-1
CCZK MINI Magnetron Sputtering Vacuum Coating Machine photo-1
US$ 50,000 - 150,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Coating Production Line
Substrate:
Steel
Contact Supplier Request Quote Chat Now
Wenzhou Cicel Vacuum Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Coating Production Line
Substrate Steel
Coating Vacuum Coating
Place of Origin Zhejiang, China
Brand Name CICEL VACUUM
Model Number customized
Voltage customized
Power(W) customized
Dimension(L*W*H) customer made
Weight 4 Tons
Certification CE
Warranty 1 years
After-sales Service Provided Engineers available to service machinery overseas

1.Contact details

contact person:Rosa chen

Company Name:CICEL VACUUM COATING MACHINE CO.,LTD

ADD:Road2,Binhai Industrial park,Longwan district,Wenzhou city,Zhejiang province, 325000,China

Tel:0577-86739805 13857737962

Fax:56615100



2.Specification



Part name

Specification

Vacuum chamber

        ø1600mm×H1800mm SUS304

           vertical with double doors

Lining board

       0.6mm, SUS304

Rotation system of workpiece

           Frequency regulation

Magnetron sputtering target

        Stainless steel(L=1950mm)

Sputtering Power Supply

              50kw

Gas Flow meter

             D07-7C Series

Flow Control Instrument

             D07-7C Series

Vacuum gauge

           ZDF-5227



  valve

Main valve

              GDQ-900

Rough valve

              GDQ-200

Front valve

             GDQ-200

Vacuum

System

Diffusion pump

               KT-900

Mechanical pump

              H-150

Roots pump

           ZJY-1200A

Holding pump

              2X-30

Intelligent program

           PLC controlled+HMI

Electric element

         Standard equipment

Man-machine interaction

              Color touch screen

Pump  speed

              5×10-²pa≤4mins

Ultimate vacuum

                 5×10-4pa



3.sample

CCZK MINI Magnetron Sputtering vacuum coating machine


4.customer photo
CCZK MINI Magnetron Sputtering vacuum coating machine

5.factory information
Cicel CCZK-SF Magnetron sputtering coating Machine with high deposition rate, low temperature of substrate , well adhesion , and can achieve large area coating.

CCZK MINI Magnetron Sputtering vacuum coating machineCCZK MINI Magnetron Sputtering vacuum coating machine
our products is custom-made,if you have interest ,please contact us.
