Help CenterRouter Cnc XK1325ATC-0808
Related Products
Specifications
router cnc XK1325ATC-08081.Table size:1300*2500*300mm
2.Drive system:Japan YASKAWA
3.vaccum sunction table
4.CE and CIQ
router cnc XK1325ATC-0808
widely used in furniture, inhouse door decoration,woodworking,door carbinet.
Features:
1. Structural stability: cast steer structure makes our pouters more stable.
2.Good fitting: Taiwan Bao-yuan control system, Italy HSD spindle motor.And the spindle bearings for high-precision ceramic bearings, low noise, long life.
Adopted from Taiwan H30 straight_quadrated rail; rolling screw rod from Germany, high loading capacity and moves steadily. adopted from Japanese Yaskawa servo drive system, torque and has a perfect security system.
3.Modular structure design: Select and add a variety of machining spindle configuration, can be sculpture, engraving, milling work.
4.A simple and secure mode of operation, advanced document pre-processing to ensure the speed and accuracy of operation
5.Automatic tool changing system like bamboo leaf hats, knife storage capacity 8 (Optional)
6.High adhesion, vacuum suction device, the displacement of up to 230 cubic meters / hour
7.Compatible: Open software interface, it is compatible with type3/arteam/castmate / Wentai and etc.a variety of CAD / CAM design software generate the processing code, to ensure the design of barrier-free.
Equipment available:
a vacuum hold down
b.Auto cut adjusting device
c.Oil lubrication system
d.clamps and vacuum fitting
Specification:
Machine description |
CNC Router JA1325ATC_O8O8 |
Table size |
1350*3100mm |
Working area |
1300*2500mm |
Max cutting speed |
30000mm/min |
Max speed |
60000mm/min |
Repeat positioning accuracy |
0.05mm |
Resolution ratio |
0.025 |
Spindle rotating speed |
18000rpm/Min |
Feed in height |
300mm |
Adsorb power |
8kw |
Working Voltage |
AC380/50Hz |
Command code |
HPGL,G |
