GJYXCV4G657.A CABLE OPTIC FIBERS SELF-SUPPORTING OUTDOOR

Name: GJYXCV4G657.A CABLE OPTIC FIBERS SELF-SUPPORTING OUTDOOR
Brand: SZRUNXIANG
SKU: 105886255

US$ 0.07 - 0.2 MOQ: 5000 Meters

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SZRUNXIANG

Model Number:

GJYXCV4G657.A

Shenzhen Runxiang Telecommunication Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SZRUNXIANG

Model Number GJYXCV4G657.A

GJYXCV- METALS STRENGTHENED , PVC JACKET ,SELF-SUPPORTING BOW-TIE INTRODUCED FIBER OPTIC CABLE

FIBER SECTION DRAWING

OPTICAL FIBER STUCTURE

Singlemode Fiber size parameters		Metallic Strength Member
Fiber Type	ITU-T G.657A	Total the Number of Root	2
Fiber Specification	62.5/125/245 μm	Material	phosphated steel wire
The Number of Fibers	2 Root	Diameters	0.35+/-0.2mm
Core Diameters	62.2+/-2.5μm	Enhanced Component Hanging Wire
Core Non-circularity	≤5%	Total the Number of Root	1
Mode field Diameters	8.6~9.0+/-0.4μm	Material	phosphated steel wire
Clad Diameter	125.0+/-0.7μm	Diameters	1.20+/-0.05mm
Clad Non-circularity	≤1.0%	Thickness	0.45+/-0.05
Core/Clad Concentricity Error	≤0.5μm	Outer jacket
Coating Diameters	245+/-10μm	Material	PVC-polyvinyl chloride
Clad/Coating Concentricity Error	≤12.5μm	Color	black & white
Color Code	blue/orange/green/brown	Diameters	2.0×6.1+/-0.02mm
—	—	Making	as per customers’ requirment
