50mm Galv 90 Degree Elbow
Suitable Applications: |
Water, Oil, Gas, Petro-Chemical |
Material: |
Hot Dipped Malleable Iron |
Features: |
LONGER LASTING- Heavy duty, hot dipped galvanised |
|
HIGH PRESSURE- Banded for extra strength |
|
PIN HOLE FREE- Individually pressure tested |
|
TAPERED THREADS- Conform to (ISO 7-1) British Standards |
Technical Data | |
Max Pressure : |
16 Bar (230Psi) (1.6Mpa) |
Temperature range: |
Max Temperature : 200°C (392°F) |
Tensile Strength : |
330Mpa |
Hardness : |
HB150 (Brinell) |
Elongation Rate : |
8% |
Details | |||
Item Code |
Size |
Metric Conversion |
A |
900/0008 |
1/4 " |
8mm |
19 |
900/0010 |
3/8 " |
10mm |
24 |
900/0015 |
1/2 " |
15mm |
27 |
900/0020 |
3/4 " |
20mm |
32 |
900/0025 |
1 " |
25mm |
37 |
900/0032 |
1 1/4 " |
32mm |
44.5 |
900/0040 |
1 1/2 " |
40mm |
49 |
900/0050 |
2 " |
50mm |
57 |
900/0065 |
2 1/2 " |
65mm |
68.5 |
900/0080 |
3 " |
80mm |
77.5 |
900/0100 |
4 " |
100mm |
96.5 |
900/0150 |
6 " |
150mm |
120 |
