HT-225E Digital Concrete Test Hammer

Negotiable MOQ: 10 Units (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Tianjin, China

Brand Name:

Model Number:

HT-225E

L&T Mechanical & Electrical Equipment Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Xingang of China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Tianjin, China

Brand Name ME

Model Number HT-225E

Power Electronic

Usage Compression Testing Machine

HT-225E Digital Concrete Test Hammer

The test hammer submit to standard of JJG817-2011 and JGJ/T23-2011.

This type test hammer is used to test the concrete compressive strength of construction and bridge...

Product Description

HT-225E Digital concrete hammer (simple type). Designed for the needs of in place test for

concrete compressive strength, applied to non-destructive test (NDT)hardened concrete

compressive strength component in construct projects.

Specifications of Model HT-225E
Measuring range	10~60 Mpa
Impact energy	2.207+/-0.1J (0.225kgf.m)
Length of spring stretch	75+/-0.3mm
Tension spring stiffness	785N/m
The static friction of pointer slider	0.65N+/-0.15N
Radius of spherical tip	25+/-1mm
The average rebound values on steel anvil	80+/-2
Data storage capacity	200 standard components
Power supply	1X5# Ni-MH rechargeable battery
Housing dimension:	280*D54mm
weight	≈1kg
