HT-75 Rotary Test Hammer For Brick Ndt Equipment
HT-75 belong to light energy test hammer, used to test compressive strength of light materials like brick, thin concrete and light board.
Specifications of HT-75 | |
Impact energy: |
0.735J |
Length of spring stretch |
75mm+-0.3mm |
The static friction of pointer slider |
0.4N-0.6N |
Radius of spherical tip |
25mm+-1mm |
The average rebound values on steel anvil |
74+-2 |
Size |
54x 268mm |
weight |
1kg |
Brief introduction
Submit to standard of GB/T50315-2000,the instrument is applied to test light material such as brick, light bone concrete etc.
Trait
1)Center rod use imported material, high precision, wear proof;
2)Shell use super hard aluminums, protect instrument from damage on site test work, prolong use life;
3)Pointer slider is outside ring structure, easy to adjust friction, and assure equal friction between pointer slider and axis. And assure the precision of instrument, compare with similar other brand product, it’s good precision, longer use life and better price. Specially suitable for brick factory or brick user
HT-75 Rotary Test Hammer For Brick Ndt Equipment
