Home > Instruments & Meters > Test Instrument > Test Machine > Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel

Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel

Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel thumbnail-1
Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel thumbnail-2
Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel photo-1
Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel photo-2
US$ 2,633 - 3,650 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Tianjin, China
Brand Name:
ME
Model Number:
YQ
Contact Supplier Request Quote Chat Now
L&T Mechanical & Electrical Equipment Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang of Tianjin China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Tianjin, China
Brand Name ME
Model Number YQ
Power Electronic
Usage Auto Testing Machine

Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer  For Gasoline and Diesel







Product Description

Product Description



Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel

Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel



Main Feature





Used to measure the concentration of HC, CO, CO2, O2, NOx in the Automobile Exhaust Gas

Two kinds of Test Function: General and Two-speed idle

Full English Menu Operation

LCD (Liquid crystal) screen display

Auto-zeroing

Automatic calculation and show the air-fuel ratio

Equipped with RS232 digital serial communication interface to facilitate networking

Optional function: rotate speed and oil temperature Measurement

Equipped with functions of plate number and time display

Can store and search 500 groups of data, built-in printer

Measurable with Liquefied Petroleum Gas(LPG),Compressed Natural Gas(CNG),and gasoline and other alternative fuel vehicles





Main technical parameters



1. Environment conditions:

Temperature: -5~40℃ humidity: ≤95%

Atmosphere pressure: 670~106kps

Power supply:AC220V ±10%; 50Hz ±1Hz





2. Measurement range:

HC: 0~10000 10-6(ppm) vol

CO: 0~10.0   10-2 (%)vol

CO2: 0~20.0   10-2(%)vol

O2:0~25.0    10-2 (%) vol

NOx:0~5000  10-6(ppm)vol

Rotate speed: 0~10000rpm

Oil temperature: 0~120 ℃





3. Response Time:



CO, HC, CO2≤10S ; NOx, O2≤15S



4. Indication Error:



CO: ±5% (relative error: 0-10%)

CO2: ±5% (relative error: 0-20%)

HC:±5% (relative error: 0-2000ppm vol Hexane equivalent)

±10% (relative error:2001-9999ppm vol Hexane equivalent)

O2: ±5% (relative error: 0-20.9%)

NOx: ±4% ( relative error)







Packaging & Shipping



Packing List



Item

Description

Qty







1



Petrol and Diesel Exhaust Testing and Fault Diagnosis System

main body



1




 2



Test Unit



 1




3

Test Unit’s Interface Connection

1







4

Standard Gas

2







5

Optical Filter

1







6

Emission Analyzer Sampling Probe

1







7

Smoke Meter Sampling Probe

1







8

User’s Guide

1







9

Special Filter

1







10

220V Power Line

1







11

Prepositive Filter

1







12

Front Filter

8







13

Tail Pipe(1m)

2







14

Printer Paper

1







15

Specialized Spanner

1







16

Network Tie-In

1







17

Pump Cover

2







18

Filter Element for Oil-water Separator

2







19

Measurement Unit Bracket

1







20

Installation Screw

M16*16 8pc







21

Test Unit Brush

1







22

Fuse

2









 Click pictures for details



5 Gas Type Emission Analyzer 4 Gas Type Emission Analyzer  2 Gas Type Emission Analyzer
Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel
Smoke Meter



Petrol and Diesel Exhaust Gas Analyzer



Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel

 Competitive Price HC, CO, CO2, O2, NOX Gas Analyzer For Gasoline and Diesel

SV-D1T (Point Display) Vehicle Headlight Tester

SV-D5T (LED Display)Vehicle Headlight Tester
