desktop fiber laser marking machine laser engraving machine for jewelry
Advantage
Fiber laser marking machine are third-generation laser marking systems successfully researched and
developed by the company by employing cutting-edge laser technologies in the world. The optical fiber laser is
employed for laser output, and super high-speed scanning system is employed to achieve marking. The
optical fiber laser markers feature high efficiency in electrical/optical conversion, and wind cooling is employed.
The whole system is small in size, with high beam output quality, high reliability, super long service life, and s
aving energy. The markers are used for fields with higher requirements in depth, smoothness and precision.
Features
1.Fast processing speed-Its processing speed is 2-3 times of traditional laser marking machine.
2.Good Stability and Free Maintenance,No need maintenance for laser device, also not need adjust or clean the lens.
3.Long Using Time -the average using time more than 100,000 hours.
4.User-friendly interface, easy operation
5.Applicable to a variety of materials such as nylon, ABS,PVC, PES, metal, titanium, copper etc
Applications
Mobile phone keypads, nonopaque-plastic keypads, electronic components, integrated circuits (IC), electrical appliances, communication products, sanitary wares, tool accessories, cutters, watches, glasses, jewelry, auto parts, boxes, bags, clasps, cookers, stainless steel products, etc.
Technical parameter
| Model | SW-FLM Fiber laser marker series |
| Mean laser power | 10W |
| Laser wavelength | 1064nm |
| Laser Repetition frequency | 20-100KHz |
| Marking area | 110×110mm |
| Marking size optional | 50x50mm,70x70mm,150x150mm,175x175mm,200x200mm |
| Marking depth | ≤0.8mm |
| Linear speed | ≤10000mm/s |
| Min. line width | 0.01mm |
| Min. letter | 0.2mm |
| Repeatability | ±0.002mm |
| Supported format | Support AI,PLT, DXF, BMP,JPG file, etc. |
| Power supply | AC220V±10%/50Hz-60Hz, AC110V optional. |
| Power consumption | 0.5KW |
| Laser cooling | Air cooling |
| Host dimension(L*W*H) | 1200x630x1400mm |
Machine&Sample
After-sale services
1. International quality certificate, FDA,CE,ISO9001
2. 100,000 hours lifetime, free maintenance.
3. Engineers available to service machinery overseas.
4. Free training for machine installation and operation.
5. Free samples marking of customer provided.
6. 24 hours technician professional and timely after-sale service.
Cetificate
FAQ
1.ARE ALL INCOTERMS CAN SUPPORT?
YES, MEET CUSTOMER'S REQUIREMENT
2.HOW LONG THE WARRENTY IS
NORMAL IS ONE YEAR, PERIOD CAN EXTEND
3.HOW TO OPERATE THE MACHINE
THERE ARE OPERATION INSTRUCTION AND VIDEO INTERPRETATION
ANY QUESTION WE WILL PROVIDE A SATISFACTORY REPLY
