Home > Packaging & Printing > Printing Machinery > Rotogravure Printing Machine > Plastic Film Rotogravure Printing Machine
US$ 40,000 - 80,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
China
Brand Name:
KETE
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanhai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Speed Computer Control Rotogravure Printing MachineUS$ 40,000 - 80,000MOQ: 1 Set -
KTHS-B Series High Speed Rotogravure Printing MachineUS$ 150,000 - 200,000MOQ: 1 Set
-
KTMS-A Series Paper Rotogravure Printing MachineUS$ 40,000 - 70,000MOQ: 1 Set
-
KTNS-B Series Rotogravure Printing Machine For SaleUS$ 5,000 - 15,000MOQ: 1 Set
-
KTHS-A Series High Speed Automatic Rotogravure Printing MachineUS$ 120,000 - 150,000MOQ: 1 Set
Condition
New
Place of Origin
China
Brand Name
KETE
Model Number
KTMS-B
Usage
Paper Printer, Other, Paper Printer, Plastic film, Aluminuc Foil
Automatic Grade
Automatic
Voltage
380V/3P
Gross Power
about 135kw
Dimensions(L*W*H)
L13500 x W2900 x H2800mm
Weight
about 17000kg
Certification
CE
Warranty
One Year
After-sales Service Provided
Engineers available to service machinery overseas
Plastic Film Rotogravure Printing Machine
Features
This Plastic Film Roto Gravure Printing Machine is suitable for roller to roller printing plastic film, aluminum Foil,BOPP, PET, PVC, PVC Foil, PE, CPP and Paper etc. It is widely use in high quality packaging material printing.
Main Technical Specification
| Main Point | Model | KTMS-B |
| Printing Colors | 2~12 Colors (base on customer requirement) | |
| Printing Material | Plastic Film / Paper / Aluminum Foil etc | |
| Printing Width | 600mm/800mm/1000mm/1200mm | |
| Heating Way | Electrical heating, Gas heating | |
| Printing speed | 120m/min | |
| Total power | About 135kw(8 color) | |
| Machine weight | About 17 Ton (8 color) | |
| Machine Size(LWH) | 13500 x 2900 x 2800mm (8 color) | |
| Unwind &Rewind | Type | Twin-reel rotating design |
| Raw Material Diameter | 600mm (Optional 800mm or more) | |
| Paper Core Diameter | 76 mm(optional152mm) | |
| Material Splicing and cutting | Manual(Optional automatic) | |
| Tension Control | Auto tension | |
| Air-shaft | Shaft type air shaft | |
| Printing Unit | Printing cylinder | Shaft-less type design |
| Printing cylinder Diameter Range | 120~300mm (special size possible) | |
| Color register precision | Vertical (Y-Axis) ≤±0.10mm (automatic) Horizontal (X-axis) ≤±0.10mm (Manual) | |
| Emboss rubber roller Diameter | 135 mm (NBR Shore (A) 60 °~ 65°) | |
| Ink recycle | Pneumatic Ink pump | |
| Control Part | Auto color register system | Include |
| Web video inspection system | include | |
| Water cooling system | Not Include(Optional possible) | |
| 3 motor drive tension system | Not include(optional possible) | |
| 7 motor drive tension system | Not include(optional possible) | |
| Ink viscosity | Not include(optional possible) | |
| Reverse Printing device | Not include(optional possible) |
