ZHANGJIAGANG LINKS MACHINE CO.,LTD,
THE GOLDEN SUPPLIER FOR DRINKS PACKAGING PLANT
XGF14-12-5 three-in-one machine for PET bottle integrates the function of rinsing, filling and capping together. Based on advanced technology overseas, and designed according to water filling processing demands
Main Machine 3 in 1 Monoblock Date Parameter
Model | XGF14-12-5 |
Amount of working position | Rinsing 14, filling 12, capping 5 |
Production capacity | 5000BPH(500ml) |
Pressure of air source | 0.5Mpa |
Air consumption | 0.6m3/min |
Rinsing water pressure | 0.2-0.25Mpa |
Rinsing water capacity | 0.8T/H |
Main motor power | 2.0kW |
Total power | 3.0kw |
Dimension | 2500X2050X2200mm (L×W×H) |
weight | 2800kg |
We provide the Complete Plant From A to Z for customer:
It Includes 4 main parts:
1/ Plastic bottle blow molding machine
2/ Water cleaning system
3/ Water washing, filling, capping machine.
4/ Conveyor system, labeling machine, dating machine, film wrapping machine
The complete line main description:
1/ The plant can produce different volume bottles, from 200ml to 2000ml bottles, round and square bottles, plastic and glass bottles. It is very easy to change the different bottle molds.
2/ The plant is highly automatic, you can operate on the touch screen to adjust the machine speed and working.
3/ We have different speed plants, commonly, 2000BPH, 4000BPH, 7000BPH, 10,000BPH, 15000BPH..ect.
4/ The material is stainless steel 304, food grade much clean and safe.
5/ We provide the engineers for customer installation, training in customer's factory.
Models and Speed List
Model | XGF8-8-3 | XGF14/12/5 | XGF16/16/5 | XGF24/24/8 | XGF32/32/10 |
Washing hands | 8 | 14 | 18 | 24 | 32 |
Filling valves | 8 | 12 | 18 | 24 | 32 |
Capping hands | 3 | 4 | 6 | 8 | 8 |
Suitable PET/Glass Bottles(150ml to 2000ml) | |||||
Capacity(Speed) Base on 500ml | 2000BPH | 5000BPH | 7000BPH | 12000BPH | 15000BPH |
Electric Components Brands Supplier
Main composition | Description Supplier |
PLC | Mitsubishi (Japan) , Siemens (Germany) |
Touch screen | Weinview(Taiwan) |
Frequency converter | Mitsubishi (Japan) , Siemens (Germany) |
Air switch | Schneider (France) |
Breaker | Siemens (Germany) |
Contactor | Siemens (Germany) |
Photoelectric switch | Omron (Japan) |
Spare Parts On Machines
1. We provide the complete machines' layout, design according to customer's factory.
2. We provide the complete English manual book for customer, all the machines' touch screen operation is English words, we have Russia, Spanish, Portuguese, French..ect to choose.
3. After delivery, we will send our engineer to customers' factory to install the machines and also train workers how to operate and maintenance. Engineer's salary: 80USD/Per day.
4. Our warranty time is 18 months after the machines installation.
If happen any question on our machine, we will response you with the solution less than 24 hours.
5. We provide the 12 months easy broken spare parts as free, and also provide the spare parts book to customer.
6. Payment method: 30% T/T as deposit after signature the contract, 70% T/T or L/C after inspection before delivery.
7 Common delivery time: 35-50days after confirm the bottle and cap design.
