bypass capacitor/decoupling capacitor
Specification of screw type low price with 1000pf capacitor :
Model of screw type low price with 1000pf capacitor |
Nominal Capacitance |
Rated Voltage(KV) of screw type low price with 1000pf capacitor |
Reactive Power |
Max. Current of screw type low price with 1000pf capacitor |
Dimensions (mm) of screw type low price with 1000pf capacitor |
Temperature Coefficient of screw type low price with 1000pf capacitor |
|||
(PF) |
DC |
HF(RMS) |
(KVA) |
(A) |
D |
M |
H |
(PPM/ °C ) |
|
MZG140 |
1000 |
20 |
85 |
100 |
30 |
140 |
25 |
50 |
-750 |
it is with mature processing technology,stable and reliable performance and complete range of models.
Features of screw type low price with 1000pf capacitor :
High voltage pulse power capacitor have the advantages of high withstand voltage,low dissipation factor,large reactive power,high frequency,long service life time and easy-installation,etc.
Application of screw type low price with 1000pf capacitor :
It's mainly used in equipment of high-frequency welded pipe,high-frequency drying,high-frequency electric oven,plastic thermal bonding machine and radio communication equipment.
Markets of screw type low price with 1000pf capacitor :
This type of ceramic capcitor sells to the Europe and America,Southeast Asia and domestic markets.this is welcomed by customers from home and abroad.
Parameters of screw type low price with 1000pf capacitor :
1.Dielectric loss <=0.0006;
2.Insulation resistance of screw type low price with 1000pf capacitor >=10000 MΩ
3.Tolerance of capacitance screw type low price with 1000pf capacitor :K(+/-10%)
4.Climate category of screw type low price with 1000pf capacitor :-40/+085/04
5.Rated temperature of screw type low price with 1000pf capacitor :+85°C
6.Testing voltage of hv ceramic capacitor :Two times of rated voltage when the nominal rated voltage<=15KV,one and half times of rated voltage when the nominal rated voltage >15KV
7.Relative Humidity of hot sale ceramic capacitors :75%
Pictures of screw type low price with 1000pf capacitor :
About us :
Dongguan Amazing Electronic Co., LTD is a professional domestic import and export type enterprise in China, engaged in capacitors. Amazing Company has been committed to the research and development of high quality aluminum electrolytic capacitors and high voltage ceramic capacitors and alternating current safety capacitors. Our products are sold to global dozens of countries and regions.
The other main capacitors:
1. MZD high voltage ceramic capacitor
2. MZA high voltage ceramic capacitor
3. MZC high voltage disc ceramic capacitor
4.MZS high voltage ceramic capacitor
