Electrolytic Capacitor 22000uf 63v

Name: Electrolytic Capacitor 22000uf 63v
Brand: Amazing
SKU: 105820159
Availability: InStock

US$ 10.5 - 20 MOQ: 5 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Amazing

Model Number:

Electrolytic capacitor 450V 1000uf

Dongguan Amazing Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Amazing

Model Number Electrolytic capacitor 450V 1000uf

Type Other, Aluminum Electrolytic Capacitor, electrolytic capacitor 22000uf 63v

Application General Purpose

Package Type Through Hole

Capacitance 4700uf

Rated Voltage 400v

Operating Temperature -45C~+135C

electrolytic capacitor 22000uf 63v

Items	Characteristics
Operating Temperature	-25~85°C
Rated Voltage Range	450V
Capacitance Tolerance	±20%(20°C, 120Hz)
Leakage Current	I less than 5mA (apply rated voltage for 5 minutes)
Leakage Current	I: leakage current(A) C: rated capacitance V: rated voltage
Dissipation Factor	Rated Voltage(V): 450V
Dissipation Factor	Tangent(Ö): 0.25Ö
Temperature Characteristics	Electrostatic Capacitance Range: c(-25°C)/C(+20°C) more than 0.7(120Hz)
Endurance	The following specification shall be satisfied when the rated voltage is applied for 2,000 hours at 85°C
	Capacitance change: ±20% of the initial value
	Dissipation factor(tg Ö): less than 200% of the initial specification value
	Leakage current: less than initial specification value
High-temperature storage	The following specifications shall be satisfied when the capacitor is stored for 500 hours at 85°C and be cooled down to 20°C and was handled according to the JIS C51024.4 term
	Capacitance change rate: ±20% of the initial testing value
	Dissipation factor(tg Ö): less than initial specification value
