1.1 Usage:
Grader of this type covers a wide range of use, including the land leveling, trenching, scratching the slope, moving earth, loosing earth, snow removing and other operations on considerably enormous floor areas such as highways, airports and farmlands.
1.2 Features:
1.2.1 The cooperation between the articulated frame and the front wheel steering promises a smaller turning radius.
1.2.2 The optimization matching on the parameters of main frame ensures a higher efficiency.
1.2.3 The rear axle, on which imported antiskid differential is installed, serves as the special triple-section drive axle for grader.
1.2.4 The power-driven gear box with six forward gears plus 3 backward gears assures the flexible control.
1.2.5 The imported HUSCO multi-way valve outputs liable performance.
1.2.6 The movement of agitator is controlled by all-hydraulic driving.
1.2.7 The adjustable control panel and driving seat are married up with the various operating handles and instruments located in accordance with the principles of ergonomics to improve the driving comfort and usage convenience.
1.2.8 The driver’s cap specially designed for grader features in its aesthetic appearance, overhead air-conditioner, together with its broad vision and brilliant tightness.
1.2.9 The adoption of hydraulic braking system and the caliper disc brake produces more stable braking performance.
1.2.10 The bulldozer, shovel tooth, Rear ripper, rotation geared ring of rubber discand the automatic leveling device are all available to users’ options.
2. Applicable environment:
2.1 Environmental temperature:
without cold starting device: -10——45℃
with cold starting device: -30——45℃
2.2 Altitude:≤3000m
Article 2. Main Technical Parameter
Whatsapp ID and Tel No': 008615980814016, Skype ID: apple-6678
Main Technical Parameter Table
|
Type Technical Parameter |
XG3165C |
Generator |
Dongfeng Cummins |
|
Type (kw/hp) Normal Rated Power(kw/hp) Rated Speed(rpm) |
6BTAA5.9-C180
132 /180 2200 |
Shovel |
|
|
Length*Chordal Height (mm) Rotating Angle(°) Inclination Angle(°) Ground Depth (mm) Driven Type |
3660×610
360 90 500 Motor + Worm Gear Case |
Gear Box |
|
Pattern |
Electro-hydraulic Shift |
Gear number |
F6/R3 |
Forward speed(Km/h) |
4.9, 7.6, 12.3, 18.5,26.8,37.1 |
Backward speed(Km/h) |
4.9,12.3,26.8 |
Driven Type |
Rear drive |
Maximum Traction(KN) |
80 |
Tire Size |
17.5-25 |
Front Axle |
|
|
Inclination Angle(°) Steering Angle(°) Swinging Angle(°) Ground Clearance(mm) |
±17 ±45 ±15
430 |
Chassis Steering Angle(°) |
Left 25 Right 25 |
Braking |
|
Service Braking Pattern |
Hydraulic caliper disc brake |
Parking Brake Pattern |
Hand drum brake |
Emergency Brake Pattern |
Hand drum brake |
Overall mass (Kg) |
14500 |
External Dimensions of classic type (mm)(L×W×H) |
8880×2595×3390 |
External Dimensions when all-equipped (mm)(L×W×H) |
10330×2750×3390 |
