Help CenterRS232 to RS485 Converter
Related Products
Specifications
Port-powered rs232 to rs485 converter;2500V isolation;
Operating temperature rangs from -10 to 60.
Industrial Port-powered RS-232 to RS-485 Serial Converter
Features |
|
1)Optical isolation effectively protects RS-232/RS-485 devices from transient surges, ground loop, and remote lightning;
|
|
2)Plug-and-Play (Device is hot-pluggable, Data format Auto-sensing & Self-adjusting);
|
|
3) Maximum baud rate 38400bps, 1200m(9600bps);
|
|
4) Port-powered, no external power or TXD, RTS, DTR required;
|
|
5) Data direction auto-turnaround, no flow control is required;
|
|
6) 2500V isolation, no power supply needed.
|
Introduction |
|
The SW485WA is an industrial grade bi-directional port-powered 2500V opto-isolated RS232 to RS485 converter in a 9 pin format. It can convert any standard full duplex RS232C port to any two-wire balanced half duplex RS485 port. In simple terms, it will convert any RS232 signal to a RS485 signal and vice versa. The unit is powered from the RS232 data lines. It also supports data direction auto-turnaround. Therefore, no external power or flow control is required. The data direction auto-turnaround automatically enables the RS485 driver when data is present on the RS232 side making the device plug-and-play, requiring no software drivers. The SW485WA has a DB9 female connector on the RS232 side and either a DB9 male connector or 3 bit terminal block on the RS485 side.
|
Specification |
Parameter |
|
Standards EIA RS-232C, RS-485 standard
|
|
RS-232 signal TX, RX, GND
|
|
RS-485 signal D+,D-,GND
|
|
Working mode Asynchronism, point to point or multi point, 2 wire half-duplex
|
|
Baud rate 300~115200bps, auto test serial signal rate detect signal speed automatically, zero delay time
|
|
Flow control Data direction auto-turnaround, no flow control is required
|
|
Max number of drops 128 nodes
|
|
Transfer distance RS-485/422 side: 1.2Km RS-232 side: no less than 5m
|
|
Optical isolation 2500V
|
|
Port protect 1500W surge protection,15KV ESD protection
|
|
Connector RS-232 side DB9 female RS-485 side DB9M( DB9F to 3 bit terminal block)
|
Power |
|
Power input No power supply need, powered from TXD, RTS,DTR
|
|
Consumption Static less than 10mA, dynamic less than 40mA
|
Environment |
|
Operating temperature -10°C to 60°C
|
|
Storage temperature -40°C to 85°C
|
|
Humidity 5% to 95% (no condensation)
|
Appearance |
|
Dimensions 95.0mm×33.0mm×16.5mm
|
|
Material Plastic (shell)
|
|
Weight 50g
|
|
Warranty 5 years
|
|
Approvals FCC, CE, RoHS
|
Packing List |
|
1) 3onedata Serial Converter SW485WA×1 2) Separate terminal block(DB9F to 3 bit)×1 3) User manual×1
|
