Burgmann Type M7N Wave Spring Mechanical Seal
US$ 5 - 100
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Style:
Mechanical Seal
Material:
Other, sic/carbon/TC
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai/others
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Standard Mechanical Seals For Pump(customers Customized)US$ 10 - 50MOQ: 5 Sets -
Type MG Burgmann Mechanical SealUS$ 8 - 70MOQ: 5 Sets
-
FLT Pump Shaft SealUS$ 5 - 100MOQ: 5 Sets
-
Tungsten Carbide BushingUS$ 5 - 100MOQ: 5 Pieces
-
RC502 Equivalent To John Crane 502/AES SealUS$ 15 - 120MOQ: 5 Sets
Standard or Nonstandard
Standard
Style
Mechanical Seal
Material
Other, sic/carbon/TC
Place of Origin
Zhejiang, China
Brand Name
Burgmann M7N/H7N
Model Number
RC-M7/H7 wave spring mechanical seal
Burgmann Type M7N Wave Spring Mechanical Seal
- We can supply M7N wave spring mechanical seal as per your requirements.
- Please feel free to contact us, we are sure both of us will have plenty of opportunities working together.
- SEND US DRAWING OR SAMPLE!!
About US: We supply kinds of elastomer mechanical seal,O-ring mechanical seal, PTFE mechanical seal and metal bellow mechanical seal,which most of mechanical seal are equivalent to Burgmann mechanical seal, John Crane mechanical seal, Pillar mechanical seals. 100% inspection, all products are checked to esure highest of standards.
Operating Conditions
- Mediums:
- Water, oil, organic liquids, middle corrosion liquids and other mediums including solid granule.
- Pressure:Up to 15bar or 218psi
- Speed: Up to 20m/s or 66ft/s
- Temperature:-40°C to 230°C or -40°F to 446°F (depending on materials used)
- To ISO 3069 and DIN 24960
Material:
- Seal face/Primary ring: Silicon carbide, Tungsten carbide, Carbon graphite..
- Seat/Mating ring: Silicon carbide, Carbon graphite, Tungsten carbide
- Secondary seals: Viton, NBR, PTFE, EPDM, Silicone
- Spring and others: SUS304, SUS316, SUS316L etc.
Features
- For plain shafts
- Single seal
- Unbalanced
- Super-Sinus-spring or multiple springs rotating
- Independent of direction of rotation
- Variant with PTFE secondary seals for high chemical resistance (M78N)
Applications
- Process industry
- Water and waste water technology
- Chemical industry
- Food and beverage industry
- Lube oils
- Low solids content media
- Water / sewage water pumps
- Chemical standard pumps
- Vertical screw pumps
- Gear wheel feed pumps
- Multistage pumps (drive side)
- Circulation of printing colors with viscosity 500 ... 15,000 mm2/s.
Advantages
- Universal application opportunities
- Efficient stock keeping due to easily interchangeable faces
- Extended selection of materials
- Insensitive to low solids contents
- Flexibility in torque transmissions
- Self cleaning effect
- Short installation length possible (G16)
- Pumping screw for media with higher viscosity (M7..F)
