Sic Sleeve Bush Bearing For Mechanical Pump Seal

US$ 5 - 100 MOQ: 5 Pieces

Key Specifications

Standard or Nonstandard:

Nonstandard

Style:

Mechanical Seal

Material:

Other, silicon carbide

Ningbo Rock Metal Product Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai/others

Delivery Detail:

Delivery time depends on order quantity.

Standard or Nonstandard Nonstandard

Style Mechanical Seal

Material Other, silicon carbide

Place of Origin Zhejiang, China

Brand Name RCM

Model Number sic sleeve

Sic Sleeve ,bearing sleeve sic bush bearing, silicone bushing

Sic Sleeve Bush Bearing For Mechanical Pump Seal

u We can supply sic sleeve as per your requirements.

u Please feel free to contact us, we are sure both of us will have plenty of opportunities

u working together. SEND US DRAWING OR SAMPLE!!

Silicon carbide is the excellent sealing material. It has light gravity, higher strength, Lower coefficient of friction, anti-radialization,

self-lubricate, easy to be matched with other materials, stable chemical characteristics, heat resistance and good heat spread

etc. According to the different production procedures, there are 2 types of silicon carbide widely used in mechanical seals,

which have different performances.

RCM-Silicon Carbide Main Performance Index

Silicon Carbide	Reaction Silicon Carbide bonded	Sintered Silicon Carbide
Purity (SIC Percentage)	>90	>97
Density (g/cm³)	3.00~3.05	3.05~3.15
Hardness (HRA)	>90	>92
Elastic Modulus (Kg/mm²)	41×10³	40×10³
Tensile Strength (Kg/mm²)	275×10³	290×10³
Bend strength (Mpa)	430	500
Compressive strength (Mpa)	2000	3500
Thermal Conductivity (W/M.K)	90.5	125.6
Coefficient of Heat Expansion (1/°C)	4.3×10^-6	4.02×10^-6
Thermal Impact Coefficient (cal/cm.s)	46.5	58.2
Heat Resistance (in the atmosphere)	1300°C	1600°C
Free-si Value (%)	≤10	≤3

We can OEM according to your drawing or sample. Any further information you need, pls send inquiry to us.
If I am off of keyboard, pls leave me a msg or email, we will reply you ASAP.
We would be your best choice! Welcome to visit our website for more details.
