E1 to V.35 Converter

Specifications

Converts V.35 interface into E1 (2M unframed G.703) interface

1) Convert V.35 interface into E1 (2m unframed G.703) interface
2) Support line recovery clock, local clock and equipment clock
3) Support E1 port loop and V.35 port loop
4) E1 (G.703) interface support 120 (RJ-45) and 75 (BNC double coaxial)

Specifications:
1) Interface standard: ITU-T G.703, CCITT V.35
2) E1 signal (BNC): in, out
3) E1 signal (RJ-45): T+, T-, R+, R-, GND
4) Working: asynchronous, lucency transmission
5) E1 interface rate: 2.048Mbps
6) V.35 interface rate: 2.048Mbps
7) E1 port coding: HDB3
8) V.35 port coding: NRZ
9) E1 port transmission: 2km
10) E1 port protection: 1500V electromagnetism isolation
11) V.35 port protection: 600W surge protection, 15KV static protection
12) E1 port type: 120 (RJ-45) and 75 (BNC double coaxial)
13) V.35 port type: DB-25 female or M/34 female
14) Operating temperature: -25 to 70°C
15) Storage temperature: -40 to 85°C
16) Relative humidity: 5% to 95%
17) Input power: 220VAC
18) Consumption: 2W
19) Dimensions (L x W x H): 227 x 147 x 42mm
20) Shell: plastic
21) Color: black
22) Weight: 260g
