Help CenterLAY5 EL8425 IP40 Double Flush Pushbutton
Related Products
-
LAY5 EC42 Mushroom PushbuttonUS$ 0.3 - 1.5MOQ: 200 Pieces -
LAY5 EL9325 IP65 Double Head ButtonUS$ 0.3 - 1.5MOQ: 200 Pieces
-
LAY5 ED21 Selector Pushbutton SwitchUS$ 0.3 - 1.5MOQ: 200 Pieces
-
LAY5 EL8325 IP40 Double Head Pushbutton SwitchUS$ 0.3 - 1.5MOQ: 200 Pieces
-
LAY5 ED33 Two Positions SwitchUS$ 0.3 - 1.5MOQ: 200 Pieces
Specifications
1. LAY5 EL8425 double head pushbutton switch2. Twin pushbutton
3. CE approval
4. NO,NC,start stop
LAY5 series pushbutton switch
- Application
LAY5 Series pushbutton switch can be used in industrial control circuit with voltage up to AC380V 50/60Hz or DC 250 as control functions of electromagnetic starter, contactor, relay and other electrical lines.
- Technical parameter
Rated insulation voltage Ui (V) |
380 |
||||
Conventional air thermal current I th(A) |
10 |
||||
Rated working voltage Ue (V) |
380 |
250 |
240 |
125 |
|
Rated working current Ie(A) |
AC-15 |
2.5 |
- |
3 |
- |
DC-13 |
- |
0.27 |
- |
0.55 |
|
- Material
Model |
Head |
Bezel |
Contact |
Button enclosure |
LAY5-B metal series |
Zinc alloy |
Zinc alloy |
Silver alloy |
PBT |
LAY5-E plastic series |
Nylon |
Nylon |
- Pushbutton Property
Ambient temperature |
-25°C~+55°C |
Vibration resistance |
<500Hz, amplitude is about 0.1mm |
Shock Resistance |
≥10g |
Ingress protection |
IP40, or IP65 as per special requirement |
Standards |
GB14048,IEC60947 |
- Contact Property
Contact action |
Slow move ( NO or NC), |
Contact resistor |
≤50mΩ |
Mechanical life |
Self spring return type more than 1 million times Other types more than 0.1 million times |
Electrical life |
AC more than 0.1 million times |
Short circuit protection |
RT16-10A |
Wiring |
Screw compression type terminal Wiring size: Min 1x0.5 sq mm Max. with cable lugs2x1.5 sq mm, Without cable lugs 1x2.5 sq mm |
- Selection Model
