Big Power Mini Metal Gear Milling Machine small cnc lathe
Feature:
1. Motor case and headstock are jointed. Maximum motor power is 144W by using more powerful motor. It can machine gears. Some parts are electroplated to make the machine more beautiful and practical.
2.Main parts: headstock, long machine bed, short machine bed ,big slider, small slider, motor blade, connection piece, dividing positioner ,gear etc. All of the parts above are made of metal.
3.By using dividing plate, we can drill the round workpiece equally.
4. There are three circles of holes on the dividing plate and each circle with the same ratio holes. The number of the holes on each circle is respectively 36,40,48. We can choose them as needed.
Technical parameters:
1.Motor speed :12,000rpm/min(optional choice 20,000rpm/min)
2.Input voltage/current/power:12VDC/5A/60W
3.Working material: wood, engineering plastic, soft metal( gold, silver, copper, aluminum etc.)
4.Maximum working material diameter clamped by three-jaw chuck:50mm
5.The transformer has over-current protection , over-voltage protection, over-heating protection .
6.With 0.02mm scale line ,the handwheel increases the precision when processing.
7.Motor power :144W
8.Module :0.5, accuracy:0.03-0.05mm, formula : diameter D=module0.5*number of teeth+1
9.Axis Y /Z travel :30mm, Axis X travel:160mm
10. Working material: wood, plastic, acrylic, soft metal(gold, silver, copper, aluminum etc.)
Packaging:
Packaging material: Carton/Wooden case with foam inside.
Shipping:
A. 3-5 workdays shipping from China by Air/Express(DHL,FedEx,UPS,EMS etc.)
B. 3-5 workdays shipping from UK Warehouse to European union countries.No need to pay for customs duties and VAT.
C. 25-30 workdays shipping from China to Russian customers. No need to pay for customs duties and VAT.
D. We can arrange shipment by sea. Minium CBM requirement : 1 CBM
1.We provide you the friendly English User manual or operating videos for free.
2.24 hours technical support by email or calling.
3.Warranty: 1 year free, 2-3 years cost price and free technical support always.
4.Free training to make sure you master the operating of our products.
5. OEM/ODM accept . But the MOQ of OEM/ODM is 100 sets.
USBEARTH factory is located in Shenzhen, China.
Our factory owns 2 brands , Lybga and usbearth.
We has 10 years experiences in manufacturing and exporting BGA rework stations.
Our BGA rework stations , such Ly IR6000, Ly IR6500, Ly IR9000,Ly IR-PRO-SC, Ly IR8000, Ly HR560, Ly HR560C, Ly HR500, Ly SV550C, Bauer IR-PRO-SCC ,Bauer OMEGA XD …
CNC machines like cnc 3020/4030/6040/9060 …series products ,Mobile LCD separating stationslike 946D /947B /950V/948V/948B…are hot sale in the world, especially in these countries from North and South American,European and Asian.
