Specifications
CE, ROHS approved1 year warranty
Optional sensor styles and colors
MOQ: 5PCS
Parking Sensor for Parking Guidance System Parking Control
· Automatic activation when powered and reverse gear is selected
· High brightness LED indicates distance and orientation of obstacles
· Front 2 and rear 4 sensors for full coverage detection
· Self-diagnosis function
· Compatible with tow bar or back tyre on the rear of vechicle
· Integrated beeper for immediate alert
· 3 stages warning by different beeping frequency and 3 colors LED
· Power supply: DC10.5V-15V(12V normal)
1. Technical data
Supply voltage |
10.5V ~15V (12V nominal) |
Current consumption |
200 mA max |
Working temperature |
-30°C ~ 70°C |
Storage temperature |
-35°C ~ 75°C |
Obstacle detection |
From 150 cm from the bumper (post dia. 80 mm) |
Reliability over time |
Satisfies the strictest automotive standards |
2. Self diagnosis function
3. Distance Ajusting Modes
4. Sensor
5. Signal
Obstacle distance |
Distance category |
Beep |
LED |
150 ~ 110 cm |
Safety |
Din……Din……Din….. |
1.5m ~1.1m |
100 ~ 60 cm |
Cautious |
Din…Din…Din…Din… |
1.0m ~0.6m |
50 ~ 30 cm |
Hazard |
Din..Din..Din..Din..Din..Din.. |
0.5m ~0.3m |
Less than 30 cm |
Hazard |
Din..Din..Din..Din..Din..Din.. |
P_ |
6. Pack contains:
1 * command module 6 * ultrasonic sensors 1 * acoustic indicator
1 * power supply cable 1 * hole borer 1 * accessory kit
1 * instruction manual
