china factory impact crusher machine for sale
- 60 Set / Sets per Month
- Qingdao China
- T/T
- Tertiary Reversible Impact Hammer Crusher with High Chrome Blow Bar
- China Wheat and Grain Transport Vibrating Feeder Price in Shanghai
- Good Quality Heavy Hammer Crusher for Crushing All Kinds of Ores
- Sand Ore and Coal Vibrating Feeder Machinery Used in Mining Industry
- High Efficiency Stone Crushing Plant Impact Stone Crusher
- Sound Equipment Impact Crusher Machine for Stone Crushing Line
Product Details
Condition: | New | Type: | Impact Crusher | Application: | electricity and highway |
Motor Type: | AC Motor | Power(W): | 37-55kw | Capacity(t/h): | 30-50 |
Place of Origin: | Henan, China | Brand Name: | Hengxing | Model Number: | PF-1008 |
Dimension(L*W*H): | dia 1000x800 | Weight: | 12206 | Certification: | ISO9001:2008 |
Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
IMPACT CRUSHER
impact crusher introduction:
impact crusher can be widely used in water, electricity, highway to make suitable sand and stone. Our company impact crusher has three-cavity crush area, the rotor connected without key awl, high chrome hammer, unique impact liner, deal with hard material, high efficiency and save energy, cubic shape of product, adjustable output size.
Application:
Impact crusher can be used to crush limestone, granite, gravel, calcium carbide, quartz, dolomite, iron ore, coal, gypsum, concrete and so on.
Working principle of impact crusher:
When the impact crusher works, the motor drives the rotor rotate with high speed, on the rotor where installed the hammers. When the materials get into the area which the hammers effect, under the impact function of the hammer at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers effects for being recrushed. The materials from large to small all to be crushed at the impact chamber repeatedly. The process won't stop till the material are crushed to the required size and then discharged from outlet.
impact crusher advantages:
(1) large ratio of crushing
(2) inform granularity
(3) simple structure
(4) reliable working
(5) simple and convenient maintaining
(6) economic running expenses, etc.
Main technical parameters:
Type | Model (mm) | Feeding size (mm) | Max long size (mm) | Capacity (t/h) | Power (kw) | Weight (t) | Overall (L×W×H) (mm) |
PF-1007 | Φ1000×700 | 400×730 | 300 | 30-70 | 45 | 12 | 2330×1660×2300 |
PF-1010 | Φ1000×1050 | 400×1080 | 350 | 50-90 | 55 | 15 | 2370×1700×2390 |
PF-1210 | Φ1250×1050 | 400×1080 | 350 | 70-130 | 110 | 17.7 | 2680×2160×2800 |
PF-1214 | Φ1250×1400 | 400×1430 | 350 | 100-180 | 132 | 22.4 | 2650×2460×2800 |
PF-1315 | Φ1320×1500 | 860×1520 | 500 | 130-250 | 220 | 27 | 3180×2720×2620 |
PF-1520 | Φ1500×2000 | 830×2040 | 700 | 300-550 | 400 | 50.6 | 3959×3564×3330 |
FAQ
In order to get better effect, please kindly let us know the following information:
1. Which kind of material are you going to crush?
2. What’s the max feeding size of the material?
3. What’s the production capacity you want?
4. What’s the granularity of the final products you need?
5. Just need a impact crusher or need a complete crushing production line?
