vibrating screen
Introduction:
This series of vibrating screen moves round, it is specially designed for quarry to separate stone into different sizes. It also widely used for classification in mining, construction materials, transportation and energy etc. The series of YKYZ is the latest model in China. The eccentric shaft vibration exciter and partial block help to adjust amplitude. This machine bears the features of different specifications, reliability, strong exciter, high efficiency, little noise, durability,convenient maintenance and safety.
Features:
- YKYZ is the latest model
- Reliability
- Strong exciter
- High efficiency
- Little noise
- Durability
- Convenient maintenance and safety
Structure:
Circle vibrating screen is mainly composed of screen box, screen, vibrator,damping spring device, chassis and other components.
Principle:
Circular vibrating screen use the motor to drag the vibrator so that the screen body make periodic reciprocating vibration exciting. And the screen surface material make movement along with the screen body, so as to circular vibrating screen achieve the purpose of screening materials.
Main parameters:
Type | Screen area | Screen size (mm) | Mine density(mm) | Capacity (t/h) | Power (kw) | Weight (kg) |
2YK1235 | 2 | 5-120 | ≤400 | 60-120 | 5.5 | 3600 |
2YK1545 | 2 | 5-150 | ≤400 | 110-360 | 15 | 6400 |
3YK1545 | 3 | 5-150 | ≤400 | 110-360 | 15 | 5800 |
3YK1548 | 3 | 5-150 | ≤400 | 120-385 | 15 | 6600 |
4YK1548 | 4 | 5-150 | ≤400 | 120-385 | 15 | 7200 |
2YK1854 | 2 | 5-200 | ≤400 | 200-450 | 18.5 | 8150 |
3YK1854 | 3 | 5-200 | ≤400 | 200-450 | 18.5 | 8850 |
4YK1854 | 4 | 5-200 | ≤400 | 250-600 | 18.5 | 9550 |
3YK1860 | 3 | 5-200 | ≤400 | 250-600 | 22 | 9100 |
4YK1860 | 4 | 5-200 | ≤400 | 300-750 | 22 | 9800 |
3YK2060 | 3 | 6-200 | ≤400 | 300-750 | 37 | 10800 |
4YK2060 | 4 | 6-200 | ≤400 | 400-850 | 37 | 11800 |
3YK2460 | 3 | 6-200 | ≤400 | 400-850 | 45 | 16600 |
4YK2460 | 4 | 6-200 | ≤400 | 400-850 | 45 | 17000 |
