Specifications
Solar Air Conditioner for homes ,school,supermarket etc30%-70% electric saving
20years factory
solar air conditioner for homes
1. running principle
Chuanglan hybrid solar air-conditioner is driven by electricity and with solar energy as an auxiliary power. The two kinds of energy work complementally in accordance with principles of fluid dynamics. It combines the absorption working system to compression system by using environmental-friendly media in cooling and heating on the basic of traditional air-conditioner technology to achieve energy-saving and environment protection.
2. At presnet, Chuanglan has exported its products to more than 100 countries and regions in the five continents and established its name in the market.
3. Installation suggestions:
1) Similar to conventional ac
2) Facing south is not a must
3) Suggest outdoor unit lower than indoor unit for drain water
supplement to collector
4) When empty the air, don't forget the pipes for collector
5) Fill water when newly installed
| Model No. | TKF(R)-26GW | ||
| Power Supply:220-240VAC, 1PH, 50Hz | |||
| Performance | |||
| Capacity | Cooling | Btu/h | 9000 |
| W | 2600 | ||
| Heating | Btu/h | 10000 | |
| W | 2900 | ||
| Noise | Indoor | dB(A) | ≤40 |
| Outdoor | dB(A) | ≤50 | |
| Air Circulation | m³/h | 450 | |
| Suitable Area | m² | 11~17 | |
| EER | W/W | 3.64 | |
| Btu/h/w | 12.42 | ||
| Power Consumption | |||
| Power Input | Cooling | W | 650~770 |
| Heating | W | 650~780+350 | |
| Rated Current | Cooling | A | 2.95~3.50 |
| Heating | A | 2.95~3.55+1.6 | |
| Vacuum Tube | Diameter*Length*Pcs | 47mm*500mm*9 | |
| Dimensions | |||
| Indoor Unit | Net | mm | 785*285*210 |
| Shipping | mm | 910*370*300 | |
| Outdoor Unit | Net | mm | 790*260*540 |
| Shipping | mm | 910*370*610 | |
| Water Tank | Shipping | mm | 910*400*330 |
| Vacuum Tube | Shipping | mm | |
| Weight | |||
| Indoor Unit | Net/Gross | kg | 10/11 |
| Outdoor Unit | Net/Gross | kg | 31/34 |
| Solar Collector | Net/Gross | kg | 13/15 |
| Loading Qty | in 20feet | sets | 66 |
| 40HQ | sets | 162 | |
