Specifications
face/back:melamine paperusgae:for decorated board
original:made in china
core:poplar sheet board
Melamine paper faced plywood timber
1.Size:1220*2440mm
2. Thickness:5/7/9/12/15/18mm
3. Core: poplar,hardwood,Combi
4. Face and Back:all colors of Melamine paper
5. Glue: E2/E1/E0/MR/Melamine/WBP
6. Certification: CARB/CE
7. Grade:A/B/C class
8. Moisture Content: 6-14%
9. Density: 530-730kgs/m3
10. Formaldhyde release:E0≤0.5mg/L,E1≤1mg/L,E2≤5mg/L
11. melonBonding Strength:≥0.9mpa
12. Packing:inner with plastic bag,outside with plywood or cartons,then steel tapes for strength.
13. transportation: 8plts/20’GP,16plts/40’GP,18plts/40’HQ
14. Payment: T/T with 30% deposit or L/C at sight.
15. MOQ:1*40’HQ
16. Delivery Time: in 15 days after receiving deposit or L/C at sight.
17. Supply Ability:5000CBM per month
18. Tolerance of thickness:+/-0.2mm
19. Modulus of rupture:above 30Mpa
20. Modulus of Elasticity: above 6000Mpa
Name |
Decorative high-pressure laminate(HPL)-sheets based on thermosetting resins |
|||
Inspection Item |
Unit |
Standard Specified Value |
Inspection Result |
Decision Outcome |
Boiling water resistance |
% |
Quality increase ≤18 |
Quality increase: 14 |
Qualified |
Thickness increase ≤20 |
Thickness increase: 19 |
|||
Appearance rating not less than Grade 2 |
Grade 1 |
|||
Dry heat resistance |
-- |
Appearance gloss grade not less than Grade 3 |
Grade 1 |
Qualified |
|
Others not less than Grade 2 |
Grade 1 |
||
Impact resistance |
mm |
Notch diameter r≤10 |
6.8 |
Qualified |
Surface abrasion |
Revolutions |
≥350 |
550 |
Qualified |
Resistance to staining |
-- |
Not less than Grade 2 |
Grade 1 |
Qualified |
Cigarette ignition resistance |
-- |
Not less than Grade 2 |
Grade 1 |
Qualified |
Tensile strength |
MPa |
x≥55; Xmin≥44 |
x: 69.9; Xmin: 54.6 |
Qualified |
Resistance to cracking |
-- |
Grade 2 |
Grade 1 |
Qualified |
Dimensional Stability |
% |
Max. (L) ≤1.25 |
0.50 |
Qualified |
Max. (T) ≤0.75 |
0.20 |
Qualified |
||
Flame retarding performance |
-- |
-- |
Index of oxygen: 39% |
|
Formaldehyde released |
mg/L |
E:≤1.5 |
1.1 |
Qualified |
Notes |
-- |
|||
