JUNXBOX Premium hd Set Top Box With Fan& Jb200&wifi Antenna for North America
US$ 1 - 70
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
JUNXBOX
Model Number:
Premium HD
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangdong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Full hd 1080p Jyazbox Ultra hd V16 Satellite Receiver With Jb200 and Wifi Jyabox V16NegotiableMOQ: 1 Piece -
Full hd 1080p Jyazbox Ultra hd V16 Satellite Receiver With Jb200 and Wifi Jyazbox V16NegotiableMOQ: 1 Piece
-
Full hd 1080p Jyazbox Ultra hd V16 Satellite Receiver With Jb200 and Wifi Jyazbox V16NegotiableMOQ: 1 Piece
-
Openbox X6 1080p OriginalNegotiableMOQ: 1 Unit
-
ILINK IR210 HD With HDMI Satellite Receiver for North AmericaUS$ 45 - 49MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
JUNXBOX
Model Number
Premium HD
FTA(Free To Air)
Yes
Type
Digital
High Definition
Yes
2015 hot selling JYNX JUNXBOX Premium HD Set Top Box preinstalled FAN&jb200 8psk tuner, with WIFI usb for
North America
JUNXBOX Premium HD main features:
*Integrated JB200 Turbo 8PSK tuner
* HD H.264 /SD MPEG-2 & fully DVB-S2 compliant
* Automatic PAL / NTSC conversion
* 6000 channels TV and Radio programmable
* Blind scan and manual scan supported
* 8 different favorite groups
* Multi-language OSD
* Full Support EPG (Electronic Programming Guide)
* Support Picture in graphics (PIG)
* On-Screen Display with 65,536 color
* Multimedia Files Play by USB2.0,supported file formats:H.264,MPEG2,DivX,TS,MKV,TP,AVI,
VOB,DAT,MPG,MPEG,MOV,AAC,MP3,WMA,JPG,BMP,JPEG,PN.
* Parental lock
* Software upgrade by RS232, USB and network
* Daytime saving supported
* Automatically Timer on/off setting(multiple options)
* EN300743 DVB and EBU Tele text DVB VBI and OSD ETS300472
* Automatic save the the status when power off
* Channel list ordered in alphabetical,random, favorites, lock or satellite,etc
* Support FAT16 / FAT32 / FAT12 / NTFS
* Time shift PVR,can playback,lock,delete and rename recorded information
* Internet Key Sharing via cccam/newcamd
* Ethernet through RJ45 or WiFi
Specifications :
|
Tuning/ De-Multiplexing |
Connector Input Frequency Input Level Demod standard Demodulation FFT Mode FEC Code Rate Guard Interval Bandwidth De-multiplexer |
1 x IEC 169-24 female 75Ω for Input, 950~2150MHz Turbo 8PSK:-65dBm~-25dBm DVB-S2 (EN 300 744) and (EN302 755) ISO/IEC 13818-1; ARIB STB-B10 Turbo 8PSK, 16QAM, 64QAM for DVB-S2 Turbo 8PSK, 16QAM, 64QAM, 256QAM for DVB-S2 2K, 8K for DVB-S2 1K, 2K, 4K, 8K, 16K, 32K, 32K ext for DVB-S2 1/2, 2/3, 3/4, 5/6, 7/8 for DVB-S2 1/2, 3/5, 2/3, 3/4, 4/5, 5/6 for DVB-S2 1/4, 1/8, 1/16, 1/32 for DVB-S2 1/4, 5/32, 1/8, 5/64, 1/16, 1/32, 1/64, 1/128 for DVB-S2 6MHz, 7MHz, 8MHz MPEG2 ISO/IEC 13818-1 |
|
Video Decoding |
Standard Video Decoding Aspect Ratio Video Resolution Video Bit Rate |
ISO/IEC 13818-2 and ISO/IEC 14496-10 MPEG-2 MP@ ML for SD, MP@ HL for HD H.264/AVC MP@ L3.0 for SD, HP@ L4.1 for HD VC-1 AP@L1 for SD, AP@L3 for HD 4:3 and 16:9, HD to SD Conversion 480i/480p/576i/576p/720p/1080i/1080p MPEG-2 MP@ML: 2~15 Mbps; MPEG-2 MP@HL: <19 Mbps; MPEG-4 AVC HP@L3:<10Mbps; MPEG-4 AVC HP@L4: <20Mb |
|
Audio Decoding |
Standard Video Decoding Aspect Ratio Video Resolution Video Bit Rate |
ISO/IEC 13818-2 and ISO/IEC 14496-10 MPEG-2 MP@ ML for SD, MP@ HL for HD H.264/AVC MP@ L3.0 for SD, HP@ L4.1 for HD VC-1 AP@L1 for SD, AP@L3 for HD 4:3 and 16:9, HD to SD Conversion 480i/480p/576i/576p/720p/1080i/1080p MPEG-2 MP@ML: 2~15 Mbps; MPEG-2 MP@HL: <19 Mbps; MPEG-4 AVC HP@L3:<10Mbps; MPEG-4 AVC HP@L4: <20Mbps |
| Subtitle & Teletext |
Subtitle Teletext |
DVB Subtitle EBU TELETEXT |
| Menu Function |
Channel Search Channel -Management EPG Language Software Update Security |
Automatic search based on LCN or NIT Manual search based on Frequency and channel number Up to 10,000 channels edition,delete,move,lock,rename;8 favorite channel groups 7 days English, other languages in option loader through USB and OTA Menu lock, Parental lock, PIN lock |
|
PVR Option |
Function Profiles File System Media Format Connector |
Play/Stop/Record/Pause/Forward/Back, Scheduled Recording using EPG 3.x, 4.0, 5.0, 6.0 Home Theater & HD profiles FAT 32 MPEG2, TS, AVI, MKV, ASF, Quick, DivX,FLV, VC-1 DivX 3.X ~ 6.X,AVI,VOB,MOV,MKV,JPEG,BMP,PNG,Motion JPEG,Flash 3.1 Lite USB 2.0 supporting external hard disk of 250-500GB |
|
Front Panel |
7-Segment LED Bi-colored LED Keys |
4x7-segment LED to display channels and status information Red/Green to indicate the various states of the STB Channel Up/Down,Power |
|
Back Panel |
RF CVBS YPP HDMI Digital Audio USB RS232 Ethernet Power Port Power Swicth |
1x IEC 169-24 female for LNB signal input, 1x IEC 169-24 female for LBN signal loopout 3 x RCA female for Video, Audio Left and Audio Right 3 x YPP female for Video, Audio Left and Audio Right 1 x HDMI 1.3 with HDCP (up to 1920x1080p) 1 x S/PDIF coaxial 2 x USB 2.0 for external Hard Disk PVR function and software update 1 x RS232 port for communication and software update 1 x RJ45 1 x DC 12V/1.5A input port 1 x Power Switch for tunrning power on/off |
|
Physicals |
Power Supply Power Consumption Temperature Humidity |
DC 12V/1.5A 12W in operation <1W auto Standby Green Power Mode Operation 0~+45ºC; Storage -10~+60ºC 20~90%, non-condensed |
|
Size&Packaging |
STB Dimension Gift Box Dimension Weight Carton Information Shipment Information Accessories |
45mm(Height) x 225mm(Width) x 145mm(Depth) 65mm(Height) x 280mm(Width) x 268mm(Depth) 1.0Kg with gift box xxx mm, Gross Weight: kg, 10 STB/Carton 5000 units per 20' Feet Container Remote Control, Battery, AV Cable, User Guide, HDMI Cable in option |
|
Remote Control Unit |
Keys Mode Battery |
50 with digit,Up/Down/Left/Right/OK,Volume+/-, Program+/-,PVR keys,EPG key,etc Infra Red with 38kHz Carrier 2 x 1.5V, AAA |
Package including:
1*Premium HD BOX
1*Remote Control
1*Power Adaptor
1*AV Cable
1*IR Cable
1* WIFI USB Adapter
HDMI CABLE & Diseqc Optional
Product Photos:
