32CH Video Optical Transceiver with 1CH Reverse Data

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 500000 Piece / Pieces per Month
Port Shenzhen
Payment TermsCredit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	ONV
Model Number	ONVDT/R32V-S

Product Description

Product features

1. Card-type or Stand-alone type for your choice; suitable for concentration management in 1U Racks
2. 10 –digit coding and non-compression video transmission
3. supporting any high –resolution video signal
4. automatically compatible with PAL, NTSC and SECAM video format
5. Supporting video intact regenerative relay, the video transmission can be reach above 200km
6. Supporting advanced SNMP standards, realise long-distance web-controlling
7. LED indication of power and other parameter status, monitoring real-time operation

8. Modularized and industrialized design ensuring reliability and flexibility

The picture

Specification

Product Name	32CH Video Optical Transceiver with 1CH Data
Product Model	ONVDT/R32V1D-S
Connector Type	32 BNC video port ,data port,1 single mode single fiber FC port
Video Interface	BNC
Video Bandwidth	10MHz
Video Bit Wide	8/10/12 bit
Differential Gain	(10%-90%APL) DG <1%
Differential Phase	(10%-90%APL) DP <0.8°
Video SNR	S/N ≥ 70dB
Data Interface	industrial interface; RS-485 ,RS232 or S422
Data Bit Rate	0-1024Kbps
Power Supply	AC85-260V/50Hz
Power Consumption	18 w(Input:DC5V 5000mA)
Working Environment	environmental temperature:-40 ℃~+85 ℃, storage temperature:-45 ℃~+95 ℃, humidity:0~95%
Dimension	LxWxH: 482.6X235X44mm
Certification	FCC Class A, CE, ROHS
Warranty	3 year warranty, lifetime maintenance

Order Information(Packed in standalone and card type, Card-type is suitable for the 4U Rack)

Type Number	Specification (Interface:FC)	Max Transmission Distance (KM)
ONVDT/R32V1D-M	32 Video +1 Reverse Data	0.5KM(Multi-mode)
ONVDT/R32V1D-S	32 Video +1 Reverse Data	20KM(Single-mode)
ONVDT/R32V22D-S	32 Video +2 Bi-directional Data	20KM(Single-mode)
ONVDT/R32V2D2K-S	32 Video+2 Reverse Data+ 2 Alarm	20KM(Single-mode)
ONVDT/R32V82D-S	32 video+8 bi-directiona Data	20KM(Single-mode)

S40:40KM; -S60:60KM; S100:100KMNote: The interface can be ST or FC, according to the different requirements from customers. The installation size please Go refer in the application instructions Notes: :(V:video,D:data,A:audio,K:switch/alarm,E:Ethernet,P:phone,)

-S:Single-mode; -M:Multi-mode

Accessories in the Package

User Manual	maintenance card	Qualified Certification	Power Adapter	Facility
1copy	1copy	1 copy	2 pcs	1 set
