1 ch video fiber optic transmitter and receiver
Features
1.Card-type or Stand-alone type for your choice; suitable for concentration management in 2U/4U Racks
2.10 –digit coding and non-compression video transmission
3. supporting any high –resolution video signal
4.Video Band-Width: 10MHz
5.automatically compatible with PAL, NTSC and SECAM video format
6. With APC circuit, constant output optical power and wide dynamic range
7. Large capacity of gigabit optical fiber transmission, easy for upgrading
8.Supporting video intact regenerative relay
9. Supporting advanced SNMP standards, realise long-distance web-controlling
10. LED indication of power and other parameter status, monitoring real-time operation
11. Modularized and industrialized design ensuring reliability and flexibility
12. Advanced auto- adaptive technology avoiding on-site electric or optical regulation
13.Capable of auto resumption of power fuse
| Technical parameter list | |
| Product Name | 1 ch video fiber optic transmitter and receiver |
| Product Model | ONVDT/R1V-S |
| Connector Type | 1-Channel Video |
| Video Interface | BNC |
| Video Bandwidth | 10MHz |
| Video Bit Wide | 8/10/12 |
| Differential Gain | (10%-90%APL) DG<1% |
| Differential Phase | 10%-90%APL) DG<0.7dB |
| Video SNR | S/N≥70dB |
Order Information
Type Number |
Specification (Interface: FC)) |
Max Transmission Distance (KM) |
ONVDT/R1V-M |
1 Channel Video Series |
2KM(Multi-mode) |
ONVDT/R1V-S |
1 Channel Video Series |
20KM(Single-mode) |
ONVDT/R1V-S40 |
1 Channel Video Series |
40KM(Single-mode) |
ONVDT/R1V-S60 |
1 Channel Video Series |
60KM(Single-mode) |
ONVDT/R1V-S100 |
1 Channel Video Series |
100KM(Single-mode) |
Note: The interface can be ST or FC, according to the different requirements from customers. The fiber optic transmission distance can be ordered. ( 40km, 60km, 100km)
(V: video, D: data, A: audio, K: switch/alarm, E: Ethernet, P: phone)
S40: 40KM; -S60: 60KM; S100: 100KM
-S: Single-mode; -M: Multi-mode
Product Dimension Display
