8ch Video fiber optic transceiver with 8CH Video and 1ch Reverse Data
Features
1.Card-type or Stand-alone type for your choice; suitable for concentration management in 2U/4U Racks
2.10 –digit coding and non-compression video transmission
3. supporting any high –resolution video signal
4.Video Band-Width: 10MHz
5.automatically compatible with PAL, NTSC and SECAM video format
6. With APC circuit, constant output optical power and wide dynamic range
7. Large capacity of gigabit optical fiber transmission, easy for upgrading
8.Supporting video intact regenerative relay
9. Supporting advanced SNMP standards, realise long-distance web-controlling
10. LED indication of power and other parameter status, monitoring real-time operation
11. Modularized and industrialized design ensuring reliability and flexibility
12. Advanced auto- adaptive technology avoiding on-site electric or optical regulation
13.Capable of auto resumption of power fuse
Target Industries
1. Intelligent transportation supervisory system(ITS)
2. High-speed Way supervisory/Tele-Communication System
3. Security protection system, TV medical treatment
4. Long-distance Muti-media Schooling, Campus monitoring
5. Long-distance broadcast television transmission system
6. High-building Security Protection, Military Tele-Com projects
| Technical parameter list | |
| Product Name | 8ch Video fiber optic transceiver with 8CH Video and 1ch Reverse Data |
| Product Model | ONVDT/R8V1D-S |
| Connector Type | 8 BNC port, 1 data port, 1 FC fiber port |
| Video Interface | BNC |
| Video Bandwidth | 10MHz |
| Video Bit Wide | 8/10/12 bit |
| Differential Gain | (10%-90%APL) DG<1% |
| Differential Phase | 10%-90%APL) DG<0.7dB |
| Data Interface | Industrial terminal blocks; RS485,RS232 or RS422 |
| Data Bit Rate | 0-1024Kbps |
| Fiber Feature | Multi-Mode(850nm,1310nm)/Single-Mode(1310nm,1550nm);FC |
| Power Supply | External power adapter(input: AC100-240V 50/60Hz; output: 5V 2A |
| Power Consumption | 6W(Input:DC5V 2000mA) |
| Transmission Distance | Single Mode for 25km, Multi-Mode for 500m |
| Working Environment | Environment temperature: -40 ℃~+85 ℃; storage temperature:-45 ℃~+95 ℃; relative humidity: 0~95% |
| Dimension | LxWxH:206.2X206.2X45mm |
| Certification | FCC Class A, CE, ROHS |
| Warranty | 3 years |
Order Information(Packed in standalone and card type , Card-type is suitable for the 4U Rack)
Type Number |
Specification (Interface:FC) |
Max Transmission Distance (KM) |
ONVDT/R8V1D-M |
8 video + 1 reverse data |
0.5KM(Multi-mode) |
ONVDT/R8V1D-S |
8 video + 1 reverse data |
20KM(Single-mode) |
ONVDT/R8V12D-S |
8 video + 1 bi-directional data |
20KM(Single-mode) |
ONVDT/R8V82D-S |
8 video + 8 bi-directional data |
20KM(Single-mode) |
User Manual |
maintenance card |
Qualified Certification |
Power Adapter |
Facility |
1copy |
1copy |
1 copy |
1 pcs |
1 set |
Product size(mm):206.2X206.2x45
