bundy tube straightener machine
No |
Item |
Detail |
Memo |
1 |
tube diameter range |
OD 4.0—8.0mm |
/ |
2 |
tube thickness range |
0.50-0.80mm |
/ |
2 |
tube straightening length range |
100-50000mm |
/ |
3 |
straightening working speed |
>=45meter/minute |
different as tube size |
4 |
Material collection shelf |
prepared by the user |
/ |
5 |
length cutting tolerance |
+/-1mm |
/ |
6 |
power supply |
380V/50Hz |
3 phases 4 wires type |
7 |
motor power |
2.2KW, rev1440/rpm |
Material feeding motor |
0.75KW, rev1440/rpm |
cutting motor |
||
8 |
the pressure the air compressor |
1MPa |
Just need 0.6-0.8MPa in working |
9 |
dimension |
2300X1000X1350mm |
Not included the material collection shelf |
10 |
weight |
520KG |
/ |
product details
We can design the machine as the requirement of clients and supply all parts for sales service , any question and feedback, youcan contact us free.
